Запчасти Doosan Daewoo MAIN PIPING-ONE & TWO WAY FRONT PARTS

-

2400-2164

MAIN PIPING(ONE & TWO WAY)

SC: D

-2шт.

1

DS2012206

HOSE PF3/4-1600L

desc: TUYAU FLEXIBLE

2шт.

2

2184-1212D28

HOSE PF3/4-790L

desc: TUYAU FLEXIBLE

1шт.

3

2184-1197D83

HOSE PF3/4-700L

desc: TUYAU FLEXIBLE

1шт.

4

2423-1568

BLOCK

desc: BLOC

1шт.

5

2181-2627D10

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

6

S8030121

O-RING

desc: JOINT TORIQUE

10шт.

7

S8000231

O-RING

desc: JOINT TORIQUE

7шт.

8

2181-2627D1

ADAPTER

desc: RACCORD ADAPTATEUR

5шт.

9

S0558853

BOLT M10X1.5X65

desc: BOULON A 6 PANS

2шт.

10

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

11

2181-2627D3

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

12

2184-1197D73

HOSE PF3/4-960L

desc: TUYAU FLEXIBLE

1шт.

13

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

2шт.

14

2420-9635B

VALVE;SWITCH

desc: SOUPAPE A SOLENOIDE

1шт.

18

2181-2627D15

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

19

S8000291

O-RING

desc: JOINT TORIQUE

3шт.

20

2181-2294D6

ELBOW

desc: COUDE

1шт.

21

124-00316

CLAMP;HOSE

desc: FIXATION DE TUYAU

2шт.

22

S0559153

BOLT M10X1.5X80

desc: BOULON A 6 PANS

2шт.

24

621-03028

PLATE

desc: PLAQUE

1шт.

26

621-03029

PLATE

desc: PLAQUE

1шт.

27

S5010613

WASHER;PLAIN

desc: RONDELLE PLATE

2шт.

28

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

29

2182-1018D47

SPACER;PIPE

desc: ENTRETOISE

2шт.
