Запчасти Doosan Daewoo FRONT ONE-WAY PIPING-ARTI.BOOM OPTION PARTS

-

400-00236

FRONT ONE-WAY PIPING

SERIAL: 1269-2599

-2шт.

1

2183-3427

PIPE

desc: CONDUITE

2шт.

2

2181-2293D1

TEE PF3/4-2UNF1 3/16

desc: TE

2шт.

3

2184-1195D5

HOSE PF3/4-1450L

desc: TUYAU FLEXIBLE

2шт.

4

2184-1212D4

HOSE PF3/4-1700L

desc: TUYAU FLEXIBLE

1шт.

5

2124-1026D2

CLAMP;PIPE

desc: COLLIER

4шт.

6

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

18шт.

7

S0560753

BOLT M12X1.75X50

desc: BOULON A 6 PANS

10шт.

8

2184-1196D11

HOSE PF3/4-2150L

desc: TUYAU FLEXIBLE

2шт.

9

2181-2817D1

CAP UNF1 3/16

desc: CHAPEAU

2шт.

10

2191-3692

PLATE

desc: PLAQUE

2шт.

11

2124-1226

CLAMP

desc: COLLIER

6шт.

12

2181-2816D1

ELBOW UNF1 3/16-PF3/4

desc: COUDE

2шт.

13

S0559553

BOLT M10X1.5X100

desc: BOULON A 6 PANS

3шт.

14

S4012633

NUT M10X1.5

desc: ECROU

6шт.

15

2181-4133D12

ADAPTER UNF1 3/16-PF1

desc: RACCORD ADAPTATEUR

1шт.

16

2140-1666

PIPE;ARM

desc: CONDUITE

2шт.

17

2184-1212D3

HOSE PF3/4-1900L

desc: TUYAU FLEXIBLE

3шт.

18

2181-2566D10

ADAPTER;UNION UNF1 3/16-PF3/4

desc: RACCORD ADAPTATEUR

2шт.

19

2420-9629

VALVE;STOP

SERIAL: 1269-1993

2шт.

19

2420-9629A

VALVE;STOP

SERIAL: 1994

2шт.

20

S0511853

BOLT M10X1.5X20

desc: BOULON A 6 PANS

4шт.

21

2420-9627

VALVE;RELIEF

SERIAL: 1269-1993

1шт.

21

2420-9627A

VALVE;RELIEF

SERIAL: 1994

1шт.

22

2124-1695

CLAMP;STOP

desc: COLLIER

2шт.

23

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

24

S0561363

BOLT M12X1.75X80

desc: BOULON A 6 PANS

4шт.

25

S8000231

O-RING P22.4

desc: JOINT TORIQUE

6шт.

26

2191-4291

PLATE

desc: PLAQUE

4шт.

27

2181-2627D1

ADAPTER UNF1 3/16-PF3/4

desc: RACCORD ADAPTATEUR

2шт.

28

2158-1003D6

PROTECTOR

desc: PROTECTEUR

2шт.

29

S8030121

O-RING F12

desc: JOINT TORIQUE

19шт.

30

2423-1437

BLOCK

desc: BLOC

2шт.

31

S0561253

BOLT M12X1.75X75

desc: BOULON A 6 PANS

4шт.

32

2124-1025D3

CLAMP;PIPE

desc: COLLIER

6шт.

33

S8000291

O-RING P29

desc: JOINT TORIQUE

2шт.

34

2181-2566D5

ADAPTER UNF1 3/16-PFO1

desc: RACCORD ADAPTATEUR

1шт.

35

2181-4133D5

ADAPTER UNF1 3/16-PF3/4

desc: RACCORD ADAPTATEUR

4шт.

36

S8000241

O-RING P24

desc: JOINT TORIQUE

6шт.
