Запчасти Doosan Daewoo POWER TRAIN(3)-SHAFT& C/J TRACK PARTS

-

2200-1032A

POWER TRAIN(3)

SERIAL: 1-1146

-2шт.

3

2260-9401A

SHAFT;PROPELLING(FRONT)

desc: ARBRE

1шт.

4

2260-9402A

SHAFT;PROPELLING(REAR)

desc: ARBRE

1шт.

4A

06.01494-4306

BOLT M12X1.5X35

desc: . BOULON A 6 PANS

4шт.

4B

06.11063-9216

NUT M12X1.5

desc: . ECROU

4шт.

4C

S5102703

WASHER;SPRING M10

desc: . RONDELLE ELASTIQUE M12

4шт.

4D

2260-9402-08

BEARING ASS'Y

desc: . PALIER

1шт.

4E

2260-9402-03

U-JOINT ASS'Y

desc: . JOINT

1шт.

7

2480-9004B

CENTER JOINT

SERIAL: 1-607

1шт.

7

2480-9023

CENTER JOINT

SERIAL: 608

1шт.

10

S0512453

BOLT M10X1.5X40

desc: BOULON A 6 PANS

6шт.

11

S4012633

NUT M10X1.5

desc: ECROU M10X1.5

8шт.

12

2120-1339A

BOLT M10X1.0X30

desc: BOULON A 6 PANS

8шт.

13

2121-1251

NUT M10X1.0

desc: ECROU

16шт.

18

S5102901

WASHER;SPRING

desc: RONDELLE ELASTIQUE M16

7шт.

20

S0521351

BOLT M16X2.0X35

desc: BOULON A 6 PANS

4шт.

21

S4012933

NUT M16X2.0

desc: ECROU

3шт.

23

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE M10

22шт.

26

2114-1058D1

WASHER

desc: RONDELLE

2шт.

35

S0521551

BOLT M16X2.0X45

desc: BOULON A 6 PANS

3шт.

36

2621-2997

COVER

desc: COUVERCLE

1шт.

37

S5010913

WASHER;PLAIN

desc: RONDELLE

4шт.

38

2229-1070

COVER

desc: COUVERCLE

1шт.
