Запчасти Doosan Daewoo OUTRIGGER CYLINDER HYDRAULIC PARTS

-

2440-9402

CYLINDER;OUTRIGGER

SERIAL: 1-1294

2шт.

1

432.04.000

TUBE ASS'Y

desc: ENSEMBLE TUBE

1шт.

2

432.02.000

ROD ASS'Y

desc: ENSEMBLE TIGE

1шт.

3

414.00.001

SEAT;VALVE

desc: SIEGE DE VALVE

2шт.

4

432.00.004

COVER;ROD

desc: COUVERCLE DE TIGE

1шт.

5

376.00.002

PISTON

desc: PISTON

1шт.

6

412.00.003

PLUNGER

desc: PLONGEUR

1шт.

7

412.00.008

GUIDE

desc: GUIDE

2шт.

8

432.1

SEAL;PISTON

desc: JOINT

1шт.

9

432.15

RING

desc: BAGUE

2шт.

10

432.16

RING

desc: BAGUE

1шт.

11

432.2

PACKING

desc: RONDELLE D'ETANCHEITE

1шт.

12

432.3

WIPER;DUST

desc: PARE-POUSSIERE

1шт.

13

432.4

O-RING

desc: JOINT TORIQUE

1шт.

14

432.17

O-RING

desc: JOINT TORIQUE

4шт.

15

432.18

RING;BACK-UP

desc: BAGUE DE SOUTIEN

2шт.

16

432.7

O-RING

desc: JOINT TORIQUE

1шт.

17

432.19

RING;BACK-UP

desc: BAGUE DE SOUTIEN

1шт.

18

432.20

SPRING

desc: RESSORT

2шт.

19

432.21

PLUG

desc: BOUCHON

2шт.

20

432.22

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

21

432.12

NIPPLE;GREASE

desc: GRAISSEUR

2шт.

22

432.13

BUSHING

desc: MANCHON

2шт.

23

432.14

RETAINER

desc: ARRETOIR

4шт.

24

432.9

NUT

desc: ECROU

1шт.

25

432.23

BALL

desc: BILLE

2шт.
