Запчасти Doosan Daewoo BUCKET-0.5§© FRONT PARTS

-

2704-1368A

BUCKET ASS'Y-0.5M©ш

SERIAL: 1-203

1шт.

-

2704-1368B

BUCKET ASS'Y-0.5M©ш

SERIAL: 204-270

1шт.

-

2704-1368C

BUCKET ASS'Y-0.5M©ш

SERIAL: 271-380

1шт.

-

2704-1368E

BUCKET ASS'Y-0.5M©ш

SERIAL: 381-629

1шт.

-

2704-1368G

BUCKET ASS'Y-0.5M©ш

SERIAL: 630-790

1шт.

-

2704-1368H

BUCKET ASS'Y-0.5M©ш

SERIAL: 791-1394

1шт.

-

2704-1368I

BUCKET ASS'Y-0.5M©ш

SERIAL: 1395

1шт.

1

2704-1369A

BUCKET

SERIAL: 1-270

1шт.

1

2704-1369B

BUCKET

SERIAL: 271-380

1шт.

1

2704-1369C

BUCKET

SERIAL: 381-629

1шт.

1

2704-1369E

BUCKET

SERIAL: 630-790

1шт.

1

2704-1369G

BUCKET

SERIAL: 791-1394

1шт.

1

2704-1369H

BUCKET

SERIAL: 1394

1шт.

1A

2713-1222

ADAPTER;TOOTH

SERIAL: 1-380

5шт.

1A

2713-1222A

ADAPTER;TOOTH

SERIAL: 381

5шт.

2

2713-1221

POINT;TOOTH

SERIAL: 1-380

5шт.

2

2713-1221A

POINT;TOOTH

SERIAL: 381

5шт.

3

2705-1022

PIN;LOCKING

desc: GOUPILLE DE BLOCAGE

5шт.

4

2114-1859

WASHER;LOCKING

desc: RONDELLE

5шт.

5

2713-1228

CUTTER;SIDE(R)

SERIAL: 1-1394

1шт.

5

2713-1228A

CUTTER;SIDE(R)

SERIAL: 1395

1шт.

6

2713-1229

CUTTER;SIDE(L)

SERIAL: 1-1394

1шт.

6

2713-1229A

CUTTER;SIDE(L)

SERIAL: 1395

1шт.

7

S0569961

BOLT M20X2.5X55

SERIAL: 1-203

8шт.

7

S0570061

BOLT M20X2.5X60

SERIAL: 240-1394

8шт.

7

S0574561

BOLT M24X3.0X60

SERIAL: 1395

8шт.

8

S4013133

NUT M20X2.5

SERIAL: 1-1394

8шт.

8

S4013333

NUT M24X3.0

SERIAL: 1395

8шт.

9

S5103101

WASHER;SPRING M20

SERIAL: 1-629

8шт.

9

2114-9012

WASHER;HARDEN

SERIAL: 630-1394

8шт.

9

2114-1831

WASHER;HARDEN

SERIAL: 1394

8шт.
