Запчасти Doosan Daewoo WATER PUMP & COOLING FAN ENGINE PARTS

101

65.06500-6144

WATER PUMP ASS'Y

desc: POMPE DE EAU

1шт.

102

65.06501-0214

HOUSING

SC: D

1шт.

103

65.06520-6007

SEAL;MECHANICAL

desc: . JOINT

1шт.

104

65.93410-0027

BEARING

desc: . PALIER

1шт.

105

06.29020-0132

RING;SNAP

desc: . BAGUE ELASTIQUE

1шт.

106

65.06504-0033

HUB;V-BELT PULLEY

desc: . MOYEU

1шт.

107

65.06506-0085

IMPELLER

desc: . TURBINE

1шт.

108

65.06512-0016

COVER

desc: . COUVERCLE

1шт.

109

65.06901-0003

GASKET

desc: . JOINT

1шт.

110

06.04200-9009

SCREW;CROSS M8Ўї20

desc: . VIS

3шт.

111

06.01493-4215

BOLT M10Ўї1.25Ўї80

desc: BOULON A 6 PANS

1шт.

112

06.01493-4211

BOLT M10Ўї1.25Ўї60

desc: BOULON A 6 PANS

2шт.

113

06.01943-3218

BOLT ASS'Y M10Ўї1.25Ўї35

desc: BOULON A 6 PANS

1шт.

114

06.16731-2108

WASHER;SPRING

desc: RONDELLE

3шт.

115

65.06606-0039

PULLEY;FAN

desc: POLLEY

1шт.

116

65.06901B0002

GASKET

desc: JOINT

1шт.

201

65.06601-0012A

FAN;COOLING(6 BLADE)

desc: VENTILATEUR

1шт.

202

65.06611-0099

FLANGE;FAN

desc: VENTILATEUR

1шт.

203

65.06611-0089

FLANGE;FAN

desc: VENTILATEUR

1шт.

204

06.01013-9124

BOLT M8Ўї95

desc: BOULON A 6 PANS

4шт.

205

06.01923-3119

BOLT ASS'Y M8X40

desc: BOULON A 6 PANS

4шт.

206

06.15010-2311

WASHER

desc: RONDELLE

4шт.

207

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

208

06.11063-8214

NUT

desc: ECROU

4шт.

209

65.96801-0124

BELT

desc: COURROIE

1шт.
