Запчасти Doosan Daewoo TIMING GEAR CASE ENGINE PARTS

1

65.01304-0016

CASE;TIMING GEAR

desc: CARTER DE DISTRIBUTION

1шт.

2

06.22022-3119

PIN

desc: GOUJON

1шт.

3

06.01913-3113

BOLT ASS'Y

desc: BOULON A 6 PANS

4шт.

4

65.01305-0017

COVER;TIMING GEAR CASE

desc: COUVERCLE

1шт.

5

06.22022-3111

PIN

desc: GOUJON

1шт.

6

06.01913-3123

BOLT;HEX. M8X60

desc: BOULON A 6 PANS

3шт.

7

06.01913-3124

BOLT ASS'Y

desc: BOULON A 6 PANS

3шт.

8

06.01913-3117

BOLT ASS'Y

desc: BOULON A 6 PANS

3шт.

9

06.01913-3118

BOLT ASS'Y

desc: BOULON A 6 PANS

1шт.

10

65.01307-0002

COVER;TIMING CHECK HOLE

ICA: Y

2шт.

10

65.01307-0002B

COVER;TIMING CHECK HOLE

desc: COUVERCLE

2шт.

11

06.01913-2911

BOLT ASS'Y M6X16

desc: BOULON A 6 PANS

4шт.

12

65.01510-0001

SEAL;OIL(F.R)

desc: JOINT

1шт.

13

65.01903B0002

GASKET;TIMING HOLE

ICA: Y

2шт.

13

65.01903-0002C

GASKET;TIMING HOLE

desc: JOINT

2шт.

14

65.01903A0026

GASKET;COVER(T.G.C)

desc: JOINT

1шт.

15

65.01903B0004

GASKET;COVER(T.G.C)

desc: JOINT

1шт.

16

65.01307-0008

COVER;GEAR CASE P.T.O

desc: COUVERCLE

1шт.

17

06.06125-8702

BOLT;STUD M8X16

desc: BOULON A 6 PANS

1шт.

18

06.11063-8214

NUT;HEX. M8

desc: ECROU 6 PANS M8

1шт.

19

06.01913-3111

BOLT ASS'Y

desc: BOULON A 6 PANS

3шт.

20

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

1шт.

21

65.01903A0020

GASKET;COVER

desc: JOINT

1шт.

22

65.38502-0012

GEAR;IDLE P.T.O

desc: PIGNON

1шт.

23

65.38502-0005

GEAR P.T.O

desc: ENGRENAGE

1шт.

24

06.31410-1616

BEARING;BALL

desc: PALIER

4шт.

25

65.38525-0005

CASE;GEAR

desc: COUVERCLE

1шт.

26

06.06175-8305

BOLT;STUD M12X1.5X22

desc: BOULON A 6 PANS

2шт.

27

06.01913-3112

BOLT ASS'Y

desc: BOULON A 6 PANS

4шт.

28

06.01913-3123

BOLT;HEX. M8X60

desc: BOULON A 6 PANS

2шт.

29

06.01913-3116

BOLT ASS'Y M8X28

desc: BOULON A 6 PANS

1шт.

30

65.38520-0003

ADAPTER;P.T.O PUMP

desc: RACCORD ADAPTATEUR

1шт.

31

06.06226-0806

BOLT;STUD

desc: GOUJON

2шт.

32

06.11024-9203

NUT;HEX. M12X1.5

desc: ECROU 6 PANS

2шт.

33

06.16731-2109

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

34

65.38525-0001

COVER;ADAPTER

desc: COUVERCLE

1шт.

35

06.11063-8215

NUT;HEX. M10

desc: ECROU 6 PANS M10

2шт.

36

06.16731-2108

WASHER;SPRING

desc: RONDELLE

2шт.

37

65.38901A0001

GASKET;PTO COVER

desc: COUVERCLE

1шт.

38

65.38901-0014

GASKET;COVER

desc: COUVERCLE

1шт.

39

65.38901A0003

GASKET;COVER

ICA: Y

1шт.

39

65.38901-0003

GASKET;COVER

desc: COUVERCLE

1шт.

40

65.91301-0002A

POINTER

desc: POINTEUR

1шт.

41

65.05701-5143

OIL PIPE ASSY

desc: REFROIDISSEUR D'HUILE

1шт.

42

65.05401-5017

CHECK VALVE ASSY

desc: CARTOUCHE DE CONTROLE

1шт.

43

06.56180-0714

SEAL RING A10X15

desc: BAGUE D'ETANCHEITE

2шт.

44

65.98150-0056

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

45

06.56180-0712

RING;SEAL A8X14

desc: BAGUE D'ETANCHEITE

2шт.

46

65.91730-0014

SPACER

desc: BAGUE D'ECARTEMENT

1шт.

47

06.01943-3219

BOLT;HEX. M10X1.25X40

desc: BOULON A 6 PANS

1шт.
