Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

228
206
207
223
208
218
220
219
201
212
101
224
213
214
210
226
227
225
219
117
102
112
111
108
118
120
122
123
121
119
132
105
124
106
139
116
104
128
113
129
109
130
131
107
127
134
125
110
133

Артикул

Название

Примечание

Количество

101

65.03101-6049

CYLINDER HEAD ASS'Y

desc: ENSEMBLE CULASSE

1шт.

102

65.03101-1043

HEAD;CYLINDER

SC: D

1шт.

104

65.03201-1013

GUIDE;VALVE

SC: D

12шт.

105

65.03203-1020

SEAT;EXHAUST VALVE

SC: D

6шт.

106

65.03203-1019

SEAT;INLET VALVE

SC: D

6шт.

107

65.90302-0015

PLUG;CORE(NEAR FACE)

desc: . BOUCHON

1шт.

108

65.90302-0016

PLUG;CORE(EXHAUST MAIN)

desc: . BOUCHON

3шт.

109

65.90302-0019B

PLUG;CORE

desc: . COUPELLE

11шт.

110

06.15090-2313

PLUG;CORE

desc: . BOUCHON

3шт.

111

06.15090-2305

PLUG;CORE

desc: . BOUCHON

6шт.

112

65.90302-0011

PLUG;DRILLED PASS

desc: . BOUCHON

6шт.

113

65.90302-0017

PLUG;WATER JET CORE

desc: BOUCHON

6шт.

116

06.06225-0706

BOLT;STUD

desc: GOUJON

3шт.

117

06.06125-8717

BOLT;STUD

desc: GOUJON

10шт.

118

06.06125-8709

BOLT;STUD

desc: GOUJON M12X1.25X1.75X65

1шт.

119

65.91710-0004

RING;STOPPER

desc: BAGUE

2шт.

120

65.90020-0006

BOLT;CYLINDER HEAD

SERIAL: 970723

19шт.

120

65.90020-0294

BOLT;CYLINDER HEAD

SERIAL: 970724

19шт.

121

65.90020-0007

BOLT;CYLINDER HEAD

SERIAL: 970723

6шт.

121

65.90020-0295

BOLT;CYLINDER HEAD

SERIAL: 970724

6шт.

122

65.90020-0027

BOLT;CYLINDER HEAD

SERIAL: 970723

1шт.

122

65.90020-0296

BOLT;CYLINDER HEAD

SERIAL: 970724

1шт.

123

06.06125-8723

BOLT;STUD

desc: GOUJON

1шт.

124

65.19202-5005

HOOK;LIFTING

desc: CROCHET

1шт.

125

65.03901-0055

GASKET;CYLINDER HEAD

desc: JOINT

1шт.

127

65.26810-0007

CONNECTOR

desc: RACCORD

1шт.

128

06.16731-2110

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

129

06.01733-4409

BOLT;HEX M14X1.5X25

desc: BOULON A 6 PANS

1шт.

130

06.16731-2108

WASHER;SPRING

desc: RONDELLE

1шт.

131

06.01733-4208

BOLT M10X1.25X22

desc: BOULON A 6 PANS

1шт.

132

65.26803-7014B

PLUG;GLOW

desc: PRISE DE LUEUR

6шт.

133

65.19202-0005

HOOK;LIFTING

desc: CROCHET

1шт.

134

06.01943-3213

BOLT ASS'Y M10X1.25X20

desc: BOULON A 6 PANS

2шт.

139

65.04902-0011A

SEAL;VALVE STEM

desc: JOINT DE VANNE

12шт.

201

65.03401-6043A

CYLINDER HEAD COVER ASS'Y

SERIAL: 001129

1шт.

201

65.03401-6057

CYLINDER HEAD COVER ASS'Y

SERIAL: 001130

1шт.

206

65.90501-0007

NUT;CYLINDER HEAD COVER

SERIAL: 991029

4шт.

206

65.90501-0028

NUT;CYLINDER HEAD COVER

SERIAL: 991030

4шт.

207

65.90701-0018

WASHER;PLATE

SERIAL: 991029

4шт.

207

65.90701-0202

WASHER;PLATE

SERIAL: 991030

4шт.

208

65.03905-0002

GASKET;CYL. HEAD COVER

SERIAL: 991029

4шт.

208

REP_PNO: 65.90701-0202

-1шт.

208

REP_PNO: 65.90501-0028

-1шт.

208

65.03905-0023

GASKET;CYL. HEAD COVER

SERIAL: 991030

4шт.

210

65.01801-0011

CASE;BREATHER

desc: BOITE

1шт.

212

06.04190-8808

BOLT M5X16

desc: VIS

6шт.

213

06.16731-2104

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.

214

06.15010-0308

WASHER;PLAIN

desc: RONDELLE

6шт.

218

65.96301-0226

HOSE;RUBBER

SERIAL: 991112

1шт.

218

65.96301-0322

HOSE;RUBBER

SERIAL: 991113

1шт.

219

06.67020-0102

CLAMP

SERIAL: 001129

2шт.

219

06.67020-0102

CLAMP

SERIAL: 001130

1шт.

220

65.01810-5005

CAP;OIL FILLER

SERIAL: 951212

1шт.

220

65.01810-5007

CAP;OIL FILLER

SERIAL: 951213

1шт.

223

65.01801-5097

BREATHER PIPE ASS'Y

desc: CLAPET DE RECHANGE

1шт.

224

65.96501-0032B

O-RING

desc: JOINT TORIQUE 36.99x3.53

1шт.

225

65.96001-0008

CAP;RUBBER

SERIAL: 001129

1шт.

226

65.03905-0002

GASKET;CYLINDER HEAD COVER

SERIAL: 991029

1шт.

226

65.03905-0002B

GASKET;CYLINDER HEAD COVER

SERIAL: 991030

1шт.

227

65.03903-0001

PACKING;COVER

desc: RONDELLE D'ETANCHEITE

1шт.

228

65.97401-0141

CLIP;WATER HOSE

SERIAL: 000921

1шт.

228

65.97401-0144

CLIP;WATER HOSE

SERIAL: 000922

2шт.

Выбрано товаров: 62
