Запчасти Doosan Daewoo PILOT PIPING(1-1) BODY PARTS

-

2400-1781A

PILOT PIPING

SERIAL: 1382

-2шт.

1

2471-1153

FILTER;PILOT (EXPORT)

desc: FILTRE

1шт.

1A

-

HEAD

SC: D

1шт.

1B

2472-7003

CASE

desc: . CARTER

1шт.

1C

2471-1154

ELEMENT

desc: . ELEMENT FILTRANT

1шт.

1D

2426-1237

BYPASS VALVE

desc: . CLAPET DE DERIVATION

1шт.

1E

2471-1155

INDICATOR

desc: . INDICATEUR D'ELECTRIQUE

1шт.

1F

Y-3738-05

RING;BACK-UP

desc: . BAGUE D'ETANCHEITE

1шт.

1G

Y-3738-04

O-RING

desc: . JOINT TORIQUE

1шт.

1J

2530-1735

HARNESS;PILOT FILTER

desc: . FAISCEAU

1шт.

1

2471-9062

FILTER;PILOT (DOMESTIC)

SERIAL: 1756

1шт.

1A

-

HEAD

SC: D

1шт.

1B

2472-7003

CASE

desc: . CARTER

1шт.

1C

2471-1154

ELEMENT

desc: . ELEMENT FILTRANT

1шт.

1D

2426-1237

BYPASS VALVE

desc: . CLAPET DE DERIVATION

1шт.

1F

Y-3738-05

RING;BACK-UP

desc: . BAGUE D'ETANCHEITE

1шт.

1G

Y-3738-04

O-RING

desc: . JOINT TORIQUE

1шт.

2

S0553753

BOLT M6X1.0X55

desc: BOULON A 6 PANS

2шт.

3

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

2шт.

4

2181-1702D9

ELBOW PFO1/2.PF3/8

desc: COUDE

1шт.

5

S8000181

O-RING 1/2

desc: JOINT TORIQUE

4шт.

6

2181-2281D2

TEE PFO1/2XPF1/2X PF3/8

desc: TE

1шт.

8

S8000141

O-RING 3/8

desc: JOINT TORIQUE

5шт.

10

2181-1126D7

ADAPTER PFO3/8.PF3/8

desc: RACCORD

1шт.

11

2181-1126D27

ADAPTER PFO3/8.PF3/8

desc: RACCORD ADAPTATEUR

1шт.

12

2181-1702D5

ELBOW PFO.PF3/8

desc: COUDE EN S

1шт.

13

S8000111

O-RING 1/4

desc: JOINT TORIQUE

6шт.

14

2181-1126D14

ADAPTER PFO1/4.PF1/4

desc: RACCORD ADAPTATEUR

4шт.

18

2460-9054

ACCUMULATOR 0.32L

desc: RESERVOIR

1шт.

28

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE M10

2шт.

43

2181-1702D4

ELBOW PFO.PF1/4

desc: COUDE

3шт.

66

2184-1036D7

HOSE PF3/8-490L

desc: TUYAU FLEXIBLE

1шт.

68

2184-1096D22

HOSE PF3/8-300L

desc: TUYAU FLEXIBLE

1шт.

69

2184-1046D79

HOSE PF1/4-2000L

desc: TUYAU FLEXIBLE

1шт.

71

2184-1036D181

HOSE PF3/8-1200L

desc: TUYAU FLEXIBLE

1шт.

72

2184-1046D223

HOSE PF1/4-1400L

desc: TUYAU FLEXIBLE

1шт.

73

2184-1061D229

HOSE PF1/4-1850L

desc: TUYAU FLEXIBLE

1шт.

75

2184-1076D139

HOSE PF1/2-2200L

desc: TUYAU FLEXIBLE

1шт.

133

2184-1046D147

HOSE PF1/4-1000L

desc: TUYAU FLEXIBLE

1шт.

134

2181-2339D1

PLUG PF1/4

desc: BOUCHON

1шт.

150

2181-1951D19

TEE PFO1/2XPF1/2XPF1/4

desc: TE

1шт.

151

2891-1694

PLATE

desc: PLAQUE

1шт.

152

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

2шт.
