Запчасти Doosan Daewoo POWER TRAIN(3)-SHAFT& C/J POWER TRAIN

-

2200-1019

POWER TRAIN

desc: ENSEMBLE TRANSMISSION

1шт.

3

2260-9401A

SHAFT;PROPELLING

desc: ARBRE

1шт.

4

2260-9402A

SHAFT;PROPELLING

desc: ARBRE

1шт.

4A

06.01494-4306

BOLT M12X1.5X35

desc: . BOULON A 6 PANS

4шт.

4B

06.11063-9216

NUT M12X1.5

desc: . ECROU

4шт.

4C

S5102703

WASHER;SPRING M12

desc: . RONDELLE ELASTIQUE

4шт.

4D

2260-9402-08

BEARING ASS'Y

desc: . PALIER

1шт.

4E

2260-9402-03

U-JOINT ASS'Y

desc: . JOINT DE U

1шт.

7

2480-9004

CENTER JOINT

SERIAL: 1-73

1шт.

7

2480-9004A

CENTER JOINT

SERIAL: 74-2157

1шт.

7

2480-9004B

CENTER JOINT

SERIAL: 2158

1шт.

10

S0512453

BOLT M10X1.5X40

desc: BOULON A 6 PANS

6шт.

11

S4012633

NUT M10X1.5

desc: ECROU

8шт.

12

2120-1339

BOLT M10X1.0X35

desc: BOULON A 6 PANS

8шт.

13

2121-1251

NUT M10X1.0

desc: ECROU

16шт.

18

S5102901

WASHER;SPRING M16

desc: RONDELLE ELASTIQUE

3шт.

21

S4012933

NUT M16X2.0

desc: ECROU

3шт.

23

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

22шт.

26

2114-1058D1

WASHER M10

desc: RONDELLE M10

2шт.

35

S0521551

BOLT M16X2.0X45

desc: BOULON A 6 PANS

3шт.

36

2621-2997

COVER

desc: COUVERCLE

1шт.
