Запчасти Doosan Daewoo BRAKE PIPING(2)-REAR POWER TRAIN

-

2400-1437

BRAKE PIPING

SC: D

-2шт.

9

2181-1126D39

ADAPTER:S PFO1/4-PF3/8

desc: RACCORD ADAPTATEUR

1шт.

10

2184-1060D114

HOSE PF3/8-1200L

desc: TUYAU FLEXIBLE

1шт.

11

2184-1054D16

HOSE PF3/8-920L

desc: TUYAU FLEXIBLE

2шт.

13

2121-1284

NUT PF 3/8

desc: ECROU

1шт.

14

2181-2300

TEE 3-PF 3/8

desc: TE

1шт.

17

2181-1914D6

ADAPTER M14X1.5-PF3/8

desc: RACCORD ADAPTATEUR

2шт.

19

S5102901

WASHER;SPRING M16

desc: RONDELLE ELASTIQUE

2шт.

20

2181-2047A

PLUG M10X1.0

desc: BOUCHON

1шт.

22

2124-1084D2

CLIP;BAND

desc: ATTACHE

1шт.

23

S8000111

O-RING P11

REP_PNO: 8202-009

1шт.

24

S0512053

BOLT M10X1.5X25

SERIAL: 2967

4шт.

25

S5102603

WASHER;SPRING M10

SERIAL: 2967

4шт.

26

2114-1058D10

WASHER;PLAIN

SERIAL: 2967

4шт.

27

2621-3708

COVER

SERIAL: 2967

2шт.
