Запчасти Doosan Daewoo FRONT OUTRIGGER PIPING(2) OPTION PARTS

-

2400-1426

OUTRIGGER PIPING

desc: ENSEMBLE DE BEQUILLES

-2шт.

1

2420-9416A

VALVE;SELECTOR

desc: VANNE DE SELECTION

1шт.

2

S2213061

BOLT;SOCKET M10X1.5X70

desc: BOULON A 6 PANS CREUX

3шт.

3

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

3шт.

12

2181-1126D6

ADAPTER PFO1/2-PF1/2

desc: RACCORD ADAPTATEUR

1шт.

18

2184-1054D22

HOSE 1/2-770

desc: TUYAU FLEXIBLE

1шт.

21

2184-1061D158

HOSE 1/2-850

desc: TUYAU FLEXIBLE

1шт.

22

2181-1110D1

ADAPTER PT1/4-PF1/4

desc: RACCORD ADAPTATEUR

2шт.

23

2181-1951D17

TEE PFO1/2-2PF1/4

desc: TE

1шт.

24

2181-1126D24

ADAPTER PFO3/4XPF1/2

desc: RACCORD ADAPTATEUR

3шт.

25

S8000241

O-RING P24

desc: JOINT TORIQUE

4шт.

26

S8000181

O-RING P18

REP_PNO: 8202-014

1шт.

27

2184-1076D41

HOSE 1/4-1200

desc: TUYAU FLEXIBLE

1шт.

28

2184-1046D114

HOSE 1/4-1350

desc: TUYAU FLEXIBLE

1шт.

29

2184-1071D36

HOSE 1/2-800

desc: TUYAU FLEXIBLE

2шт.

32

2181-1702D4

ELBOW PFO1/2-PF1/2

desc: COUDE

1шт.

33

S8000111

O-RING P11

REP_PNO: 8202-009

1шт.
