Запчасти Doosan Daewoo OIL PIPE PARTS ENGINE PARTS

1

65.05701-5251

PIPE;OIL(PUMP TO C/B)

desc: CONDUITE

1шт.

2

06.01013-9113

BOLT;HEX. M8X40

SERIAL: 309999

4шт.

2

06.01913-3119

BOLT ASS'Y

SERIAL: 400001

4шт.

3

06.16731-2107

WASHER;SPRING

SERIAL: 309999

4шт.

3

06.16731-2107

WASHER;SPRING

SERIAL: 400001

4

65.05903-0002

GASKET

desc: JOINT

2шт.

5

65.05701-5271

PIPE;OIL(FILTER TO COOLER)

desc: CONDUITE

1шт.

6

06.01283-7118

BOLT;HEX. M8X35

SERIAL: 309999

2шт.

6

06.01913-3118

BOLT ASS'Y

SERIAL: 400001

2шт.

6

65.90001-0070

BOLT;HEX

desc: BOULON A 6 PANS

2шт.

7

06.16731-2107

WASHER;SPRING

SERIAL: 309999

4шт.

7

06.16731-2107

WASHER;SPRING

SERIAL: 400001

2шт.

8

65.05903-0001

GASKET

desc: JOINT

2шт.

9

65.05701-5200

PIPE;OIL(C/B TO I/P)

desc: CONDUITE

1шт.

10

65.98155-0011

NIPPLE

desc: GRAISSEUR

1шт.

11

06.12172-9314

NUT;CAP

desc: ECROU

1шт.

12

06.56180-0714

RING;SEAL A10X15

desc: BAGUE D'ETANCHEITE

2шт.

13

65.05401-5008

CHECK VALVE ASS'Y

SERIAL: 400166

1шт.

13

65.05401-5017

CHECK VALVE ASS'Y

SERIAL: 400167

1шт.

14

65.05701-5143

OIL PIPE ASS'Y PTO

desc: REFROIDISSEUR D'HUILE

1шт.

15

65.98150-0033

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

16

06.56180-0712

RING;SEAL A8X14

desc: BAGUE D'ETANCHEITE

2шт.

17

06.56180-0714

RING;SEAL A10X15

desc: BAGUE D'ETANCHEITE

2шт.

18

06.01493-4207

BOLT;HEX. M10X1.25X40

desc: BOULON A 6 PANS

1шт.

18

06.01943-3219

BOLT;HEX. M10X1.25X40

desc: BOULON A 6 PANS

1шт.

19

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

1шт.

19

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

20

65.91730-0014

SPACER

desc: BAGUE D'ECARTEMENT

1шт.

21

65.98155-0011

NIPPLE

desc: GRAISSEUR

1шт.

22

65.98131-5003

FLANGE

desc: BRIDE

1шт.

23

65.96601-0015

GASKET

desc: JOINT

1шт.

24

65.05701-5267

PIPE;OIL(C/B TO TURBO)

desc: CONDUITE

1шт.

25

06.01283-7113

BOLT;HEX. M8X20

SERIAL: 309999

2шт.

25

06.01913-3113

BOLT ASS'Y M8X20

SERIAL: 400001

2шт.

26

06.16731-2107

WASHER;SPRING

SERIAL: 309999

2шт.

26

06.16731-2107

WASHER;SPRING

SERIAL: 400001

27

06.01283-7110

BOLT;HEX. M8X12

SERIAL: 309999

1шт.

27

06.01913-3110

BOLT ASS'Y

SERIAL: 400001

1шт.

28

06.16731-2107

WASHER;SPRING

SERIAL: 309999

1шт.

28

06.16731-2107

WASHER;SPRING

SERIAL: 400001

29

65.97480-0315

HOLDER

desc: SUPPORT

1шт.

30

06.56180-0714

RING;SEAL A10X15

desc: BAGUE D'ETANCHEITE

2шт.

31

06.12172-9314

NUT;CAP

desc: ECROU

1шт.

32

06.78144-2403

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

33

06.56190-0704

RING;SEAL A12X18

desc: BAGUE D'ETANCHEITE

2шт.

34

65.05701-5278

PIPE;OIL(TURBO TO CAB)

desc: CONDUITE

1шт.

35

65.96601-0031

GASKET

desc: JOINT

1шт.

36

06.01283-7213

BOLT;HEX. M10X1.5X20

SERIAL: 309999

2шт.

36

06.01913-3213

BOLT ASS'Y

SERIAL: 400001

2шт.

37

06.16731-2108

WASHER;SPRING

SERIAL: 309999

2шт.

37

06.16731-2108

WASHER;SPRING

SERIAL: 400001

38

65.96301-0191

HOSE;RUBBER

desc: TUYAU CAOUTCHOUC

1шт.

39

06.67020-0106

CLAMP;HOSE

desc: COLLIER

2шт.
