Запчасти Doosan Daewoo OIL PAN ENGINE PARTS

1

65.05801-5143

PAN;OIL

desc: CARTER MOTEUR

1шт.

2

65.90310-0050

SCREW;PLUG M20X1.5

desc: VIS

2шт.

3

06.56190-0715

RING;SEAL A20X26

desc: BAGUE

2шт.

4

06.01283-7112

BOLT;HEX. M8X18

SERIAL: 309999

32шт.

4

06.01913-3112

BOLT ASS'Y

SERIAL: 400001

32шт.

5

06.16731-2107

WASHER;SPRING

SERIAL: 309999

32шт.

5

06.16731-2107

WASHER;SPRING

SERIAL: 400001

6

65.05805-5151

GAUGE;OIL LEVEL

SERIAL: 400190

1шт.

6

65.05805-5049

GAUGE;OIL LEVEL

SERIAL: 400191

1шт.

7

65.05806-5079

TUBE;GUIDE

SERIAL: 400190

1шт.

7

65.05806-5085

TUBE;GUIDE

SERIAL: 400191

1шт.

8

65.91701-0121

SPACER

SERIAL: 400120

8

65.91701-0086

SPACER

SERIAL: 400121

1шт.

9

65.05904-0002

GASKET;OIL FAN

desc: JOINT

1шт.

10

65.05903-0011

GASKET

desc: JOINT

1шт.

11

65.91615-0009

COVER;BLIND

desc: COUVERCLE BORGNE

1шт.

12

06.01283-6911

BOLT;HEX. M6X16

SERIAL: 309999

4шт.

12

06.01913-2911

BOLT ASS'Y M6X16

SERIAL: 400001

4шт.

13

06.16731-2105

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

13

06.16731-2105

WASHER;SPRING

desc: RONDELLE ELASTIQUE
