Запчасти Doosan Daewoo FLYWHEEL HOUSING ENGINE PARTS

1

65.01401-0164

HOUSING;FLYWHEEL

SERIAL: 400230

1шт.

1

65.01401-0209

HOUSING;FLYWHEEL

SERIAL: 400231

1шт.

4

06.01494-4409

BOLT;HEX. M14X1.5X50

desc: BOULON A 6 PANS

5шт.

4

06.01494-4407

BOLT;HEX. M14X1.5X40

desc: BOULON A 6 PANS

2шт.

5

06.15010-2314

WASHER

desc: RONDELLE

7шт.

13

06.16731-2110

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

14

06.11063-9217

NUT;HEX. M14X1.5

desc: ECROU 6 PANS

1шт.

15

06.22022-3111

PIN

desc: GOUJON

2шт.

17

65.96401-0007

CAP;RUBBER

desc: CHAPEAU DE CAOUTCHOUC

2шт.

18

65.91615-0007

COVER;BLIND

desc: COUVERCLE BORGNE

1шт.

18

65.91615-0007

COVER;BLIND

desc: COUVERCLE BORGNE

19

06.01283-7211

BOLT;HEX. M10X16

desc: BOULON A 6 PANS

3шт.

19

06.01283-7211

BOLT;HEX. M10X16

desc: BOULON A 6 PANS

20

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

3шт.

20

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

21

65.01904-0018

GASKET;FLYWHEEL HOUSING

desc: JOINT

1шт.

22

65.01510-0030

SEAL;OIL(RR)

SERIAL: 400150

1шт.

22

65.01510-0101

SEAL;OIL(RR)

SERIAL: 400151

1шт.
