Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

-

65.03101-6039

CYLINDER HEAD ASS'Y

SERIAL: 400030

1шт.

-

65.03101-6044

CYLINDER HEAD ASS'Y

SERIAL: 400031

1шт.

-

65.03101-6049

CYLINDER HEAD ASS'Y

SERIAL: 500044

1шт.

1

65.03101-1036

HEAD;CYLINDER

SERIAL: 400030

1шт.

1

65.03101-1038

HEAD;CYLINDER

SERIAL: 400031

1шт.

1

65.03101-1043

HEAD;CYLINDER

SERIAL: 500044

1шт.

2

65.03201-1013

GUIDE;VALVE

desc: . GUIDE DE SOUPAPE

12шт.

3

65.03203-1020

SEAT;EXHAUST VALVE

desc: . SIEGE

6шт.

4

65.03203-1019

SEAT;INLET VALVE

desc: . SIEGE

6шт.

5

65.90302-0015

PLUG;CORE(NEAR FACE)

desc: . BOUCHON

1шт.

6

65.90302-0016

PLUG;CORE(EXHAUST MAIN)

desc: . BOUCHON

3шт.

7

65.90302-0019

PLUG;CORE

desc: . BOUCHON DE DESSABLAGE

11шт.

8

06.15090-2313

PLUG;CORE NW20

desc: . BOUCHON

3шт.

9

06.15090-2305

PLUG;CORE NW12

desc: . BOUCHON

6шт.

10

65.90302-0011

PLUG;DRILLED PASS

desc: . BOUCHON

6шт.

11

65.90302-0017

PLUG;WATER JET CORE

desc: BOUCHON

6шт.

12

65.90201-0015

BOLT;STUD

desc: GOUJON

4шт.

13

06.06125-8711

BOLT;STUD

desc: GOUJON

12шт.

14

06.06225-0706

BOLT;STUD

desc: GOUJON

3шт.

15

06.06125-8717

BOLT;STUD

SERIAL: 309999

4шт.

15

06.06125-8717

BOLT;STUD

SERIAL: 400001

3шт.

16

65.90201-0016

BOLT;STUD

desc: GOUJON

4шт.

16-1

06.06125-8711

BOLT;STUD

SERIAL: 309999

4шт.

17

65.91710-0004

RING;STOPPER

desc: BAGUE

2шт.

18

65.90020-0006

BOLT;CYLINDER HEAD

desc: BOULON DE CULASSE

20шт.

19

65.90020-0007

BOLT;CYLINDER HEAD

desc: BOULON DE CULASSE

6шт.

20

65.03401-0036

COVER;CYLINDER HEAD

SERIAL: 400151

1шт.

20

65.03401-0028

CYLINDER HEAD COVER ASS'Y

SERIAL: 400152

1шт.

20

65.03401-6035

CYLINDER HEAD COVER ASS'Y

SERIAL: 500496

1шт.

21

65.97871-0229

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

22

65.90501-0007

NUT;CYLINDER HEAD COVER

desc: ECROU

4шт.

23

65.90701-0018

WASHER;PLATE

desc: RONDELLE

4шт.

24

65.90725-0002

PACKING

desc: RONDELLE D'ETANCHEITE

4шт.

25

65.03901-0032

GASKET;CYLINDER HEAD

desc: JOINT DE CULASSE

1шт.

26

65.03905-0002

PACKING;CYLINDER HEAD COVER

desc: RONDELLE D'ETANCHEITE

1шт.

27

65.01810-0001

CAP;OIL FILLER

SERIAL: 400151

1шт.

27

65.01810-5005

CAP;OIL FILLER

SERIAL: 400152

1шт.

28

65.04110-5001

SEAL;VALVE STEM

desc: JOINT DE QUEUE DE SOUPAPE

12шт.

29

65.03435-0001

COVER;FOR CYLINDER HEAD COVER

SERIAL: 400152

1шт.

30

65.03903-0001

PACKING;FOR COVER

SERIAL: 400152

1шт.

31

06.67020-0102

CLAMP;HOSE

SERIAL: 400152

1шт.

32

65.96301-0198

HOSE;RUBBER

SERIAL: 400152

1шт.

32

65.96301-0226

HOSE;RUBBER

SERIAL: 500392

1шт.

33

06.04190-8806

SCREW

SERIAL: 400152

6шт.

33

06.04190-2805

SCREW

desc: VIS

6шт.

34

06.16731-2104

WASHER;SPRING

SERIAL: 400152

6шт.
