Запчасти Doosan Daewoo COOLING WATER PUMP ENGINE PARTS

1

65.06500-6389

WATER PUMP ASS'Y

SERIAL: 400255

1шт.

1

65.06500-6395

WATER PUMP ASS'Y

SERIAL: 400256

1шт.

2

65.06501-0004

HOUSING

desc: . BOITIER

1шт.

2

65.06501-0068

HOUSING

desc: . BOITIER

1шт.

3

65.06520-6006

SEAL;MECHANICAL

desc: . JOINT

1шт.

3

65.06520-6007

SEAL;MECHANICAL

desc: . JOINT

1шт.

4

65.06505-0023

SHAFT

desc: . ARBRE

1шт.

4

65.93410-0024

BEARING;UNIT

desc: . PALIER

1шт.

5

06.31430-0312

BEARING;BALL

desc: . PALIER

1шт.

5

06.31430-0312

BEARING;BALL

desc: . PALIER

6

06.31430-0512

BEARING;BALL

desc: . PALIER

2шт.

6

06.31430-0512

BEARING;BALL

desc: . PALIER

7

65.06508-0010

SPACER

desc: . DOUILLE D'ECARTEMENT

1шт.

7

65.06508-0010

SPACER

desc: . DOUILLE D'ECARTEMENT

8

06.29020-0128

RING;SNAP

desc: . BAGUE ELASTIQUE

1шт.

8

06.29020-0128

RING;SNAP

desc: . BAGUE ELASTIQUE

1шт.

9

65.06504-0002

HUB

desc: . MOYEU

1шт.

9

65.06504-0033

HUB

desc: . MOYEU

1шт.

10

65.06506-0016

IMPELLER

desc: . TURBINE

1шт.

10

65.06506-0021

IMPELLER

desc: . TURBINE

1шт.

11

65.06512-0002

COVER

desc: . COUVERCLE

1шт.

12

65.06901-0003

GASKET

desc: . JOINT

1шт.

13

06.04200-9009

SCREW;CROSS M8X20

desc: . VIS

3шт.
