Запчасти Doosan Daewoo COOLING SYSTEM ENGINE PARTS

1

65.06601-0012

FAN;COOLING

desc: VENTILATEUR

1шт.

2

65.06611-0072

FLANGE;FAN

SERIAL: 400255

1шт.

2

65.06611-0099

FLANGE;FAN

SERIAL: 400256

1шт.

3

65.06611-0089

FLANGE;FAN

desc: BRIDE

1шт.

4

06.01013-9124

BOLT;HEX. M8X95

desc: BOULON A 6 PANS

4шт.

5

06.01013-9113

BOLT;HEX. M8X40

SERIAL: 309999

4шт.

5

06.01913-3119

BOLT ASS'Y

SERIAL: 400001

4шт.

6

06.15010-2311

WASHER;PLAIN

SERIAL: 309999

8шт.

6

06.15010-2311

WASHER;PLAIN

SERIAL: 400001

4шт.

7

06.16731-2107

WASHER;SPRING

SERIAL: 309999

8шт.

7

06.16731-2107

WASHER;SPRING

SERIAL: 400001

4шт.

8

06.11063-8214

NUT;HEX. M8

desc: ECROU 6 PANS M8

4шт.

9

65.96801-0095

V-BELT(1260)

desc: COURROIE

1шт.

10

06.01493-4214

BOLT;HEX. M10X1.25X70

desc: BOULON A 6 PANS

1шт.

11

06.01493-4209

BOLT;HEX. M10X1.25X50

SERIAL: 309999

2шт.

11

06.01943-3221

BOLT ASS'Y M10X1.25X50

SERIAL: 400001

2шт.

12

06.01493-4206

BOLT;HEX. M10X1.25X35

desc: BOULON A 6 PANS

1шт.

12

06.01513-3218

BOLT;HEX. M10X1.25X35

desc: BOULON A 6 PANS

1шт.

13

06.16731-2108

WASHER;SPRING

SERIAL: 309999

4шт.

13

06.16731-2108

WASHER;SPRING

SERIAL: 400001

2шт.

13

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

14

65.06503-0061

PULLEY;V-BELT

SERIAL: 400255

1шт.

14

65.06503-0076

PULLEY;V-BELT

SERIAL: 400256

1шт.

15

65.06901-0002

GASKET

desc: JOINT

1шт.

16

65.06404-0003

HOUSING ASS'Y

desc: ENSEMBLE DE CORPS DE VANNE

1шт.

17

65.06402-5004

ELEMENT;THERMOSTAT

desc: ELEMENT FILTRANT

1шт.

18

65.06405-0012

OUTLET;WATER

desc: SORTIE A EAU

1шт.

19

06.01283-7114

BOLT;HEX. M8X22

SERIAL: 309999

3шт.

19

06.01923-3114

BOLT ASS'Y

SERIAL: 400001

3шт.

20

06.16731-2107

WASHER;SPRING

SERIAL: 309999

3шт.

20

06.16731-2107

WASHER;SPRING

SERIAL: 400001

21

06.15010-2311

WASHER;PLAIN

SERIAL: 309999

3шт.

21

06.15010-2311

WASHER;PLAIN

SERIAL: 400001

22

06.01493-4218

BOLT;HEX. M10X1.25X95

SERIAL: 309999

3шт.

22

06.01493-4217

BOLT;HEX. M10X1.25X95

SERIAL: 400001

3шт.

23

06.01493-4206

BOLT;HEX. M10X1.25X35

SERIAL: 309999

3шт.

23

06.01733-4211

BOLT;HEX. M10X1.25X35

SERIAL: 400001

3шт.

23

06.01943-3217

BOLT;HEX. M10X1.25X35

desc: BOULON A 6 PANS

3шт.

24

06.16731-2108

WASHER;SPRING

SERIAL: 309999

6шт.

24

06.16044-0211

WASHER;SPRING

SERIAL: 400001

6шт.

25

06.15010-2312

WASHER;PLAIN

SERIAL: 309999

6шт.

25

06.15010-2312

WASHER;PLAIN

SERIAL: 400001

26

06.08092-2405

SCREW;PLUG M16X1.5

desc: VIS

1шт.

27

06.56190-0709

RING;SEAL A16X22

desc: BAGUE D'ETANCHEITE

1шт.

28

66.27435-6007

SWITCH;THERMO. 10

desc: INTERRUPTEUR

1шт.

30

65.96301-0045

HOSE;RUBBER

desc: TUYAU CAOUTCHOUC

1шт.

31

06.67020-0106

CLAMP;HOSE

desc: COLLIER

2шт.

32

65.06904-0004

GASKET

desc: JOINT

1шт.

33

65.06904-0003

PACKING

desc: RONDELLE D'ETANCHEITE

1шт.

34

65.05601-7056

OIL COOLER ASS'Y

desc: ENSEMBLE REFROIDISSEUR D'HUILE

1шт.

35

06.01013-9118

BOLT;HEX. M8X65

SERIAL: 309999

1шт.

35

06.01923-3124

BOLT ASS'Y

SERIAL: 400001

1шт.

36

06.01013-9114

BOLT;HEX. M8X45

SERIAL: 309999

12шт.

36

06.01923-3120

BOLT ASS'Y

SERIAL: 400001

12шт.

37

06.01923-3115

HEX. BOLT ASS'Y M8X25

desc: BOULON 6 PANS

15шт.

38

06.01283-7113

BOLT;HEX. M8X20

SERIAL: 309999

2шт.

38

06.01923-3113

BOLT ASS'Y

SERIAL: 400001

2шт.

39

06.16731-2107

WASHER;SPRING

SERIAL: 309999

15шт.

39

06.16731-2107

WASHER;SPRING

SERIAL: 400001

40

06.15010-2311

WASHER;PLAIN

SERIAL: 309999

15шт.

40

06.15010-2311

WASHER;PLAIN

SERIAL: 400001

41

65.05902-0005

GASKET

desc: JOINT

1шт.
