Запчасти Doosan Daewoo MAIN PIPING(3)-DX22 BODY PARTS

-

2400-1564

MAIN PIPING

SERIAL: 1-1726

-2шт.

-

2400-1564A

MAIN PIPING

SERIAL: 1727

-2шт.

23

2181-4133D5

ADAPTER UNF1 3/16-12XPF3/4

desc: RACCORD ADAPTATEUR

1шт.

24

S8030121

O-RING F12

desc: JOINT TORIQUE

2шт.

25

S8000241

O-RING P24

SERIAL: 1-1350

4шт.

25

S8000231

O-RING P23

SERIAL: 1351

4шт.

30

2184-1036D253

HOSE(DOZER) PF1/2-1400L

SERIAL: 1-1350

2шт.

30

2184-1036D236

HOSE(DOZER) PF1/2-1250L

SERIAL: 1351

2шт.

31

2181-1126D24

ADAPTER PFO3/4-PF1/2

desc: RACCORD ADAPTATEUR

1шт.

43

S8000141

O-RING P14

REP_PNO: 8202-011

2шт.

44

2181-1126D7

ADAPTER PFO3/8-PF3/8

desc: RACCORD ADAPTATEUR

2шт.

45

2184-1096D6

HOSE PF3/8-480L

SERIAL: 1-2405

1шт.

45

2184-1096D3

HOSE PF3/8-480L

SERIAL: 2406

1шт.

48

2181-4133D14

ADAPTER PFO3/4-ORS 3/4

desc: RACCORD ADAPTATEUR

1шт.

49

2184-1201D4

HOSE(TRAVEL) ORS3/4 SAE1-1500L

SERIAL: 1-1350

1шт.

49

2184-1201D8

HOSE(TRAVEL) ORS3/4 SAE1-1400L

SERIAL: 1351

1шт.

50

2184-1201D3

HOSE(TRAVEL) ORS3/4 SAE1-1400L

SERIAL: 1-1350

1шт.

50

2184-1201D11

HOSE(TRAVEL) ORS3/4 SAE1-1400L

SERIAL: 1351

1шт.

51

2180-1026D19

O-RING SAE 1"

desc: JOINT TORIQUE

2шт.

52

2181-9059

FLANGE;SPLIT 1-600PSI

desc: FLASQUE EN DEUX PARTIES

2шт.

53

2181-9084

FLANGE;SPLIT SAE1 SPECIAL

desc: FLASQUE EN DEUX PARTIES

2шт.

54

S2215461

BOLT;SOCKET M12X1.75X40

desc: BOULON A 6 PANS CREUX

8шт.

63

2181-1126D6

ADAPTER PFO1/2-PF1/2

desc: RACCORD ADAPTATEUR

2шт.

64

S8000181

O-RING P18

REP_PNO: 8202-014

2шт.

68

2181-1564

ADAPTER PFO3/4-PF1/2

SERIAL: 1-1350

1шт.

68

2181-1564A

ADAPTER PFO3/4-PF1/2

SERIAL: 1351

1шт.
