Запчасти Doosan Daewoo BRAKE PIPING(2) BODY PARTS

-

2400-1607

BRAKE PIPING

SERIAL: 98

-2шт.

5

2471-9027

FILTER

desc: FILTRE

1шт.

5A

Y-4143-01

BODY

desc: . CULASSE

1шт.

5B

Y-4143-06

VALVE ASS'Y

desc: . VANNE

1шт.

5C

2474-9042

ELEMENT

desc: . ELEMENT FILTRANT

1шт.

5D

Y-4143-05

O-RING

desc: . JOINT TORIQUE

1шт.

5E

Y-4143-04

RING;BACK-UP

desc: . RESSORT

1шт.

5F

Y-4143-02

CASE

desc: . CARTER

1шт.

5G

Y-4117

INDICATOR

desc: . INDICATEUR D'ELECTRIQUE

1шт.

6

S0553753

BOLT M6X1.0X55

desc: BOULON A 6 PANS

2шт.

7

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

8

S8000181

O-RING P18

REP_PNO: 8202-014

6шт.

9

2181-1702D2

ELBOW PFO1/2-PF1/2

desc: COUDE

1шт.

10

2181-9089

FLANGE;SPLIT SAE 1/2

desc: FLASQUE EN DEUX PARTIES

2шт.

11

2180-1026D30

O-RING SAE 1/2

desc: JOINT TORIQUE

1шт.

12

S2209061

BOLT;SOCKET M8X1.25X25

REP_PNO: 8072-084

4шт.

13

S5110503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

15

2184-1095D9

HOSE 1/2-390L

desc: TUYAU FLEXIBLE

1шт.

16

2184-1036D71

HOSE 1/2-2100L

desc: TUYAU FLEXIBLE

1шт.

17

2181-1126D6

ADAPTER PFO1/2-PF1/2

desc: RACCORD ADAPTATEUR

3шт.

18

2184-1096D27

HOSE 1/2-650L

desc: TUYAU FLEXIBLE

1шт.

23

2181-1126D7

ADAPTER PFO3/8-PF3/8

desc: RACCORD ADAPTATEUR

2шт.

24

S8000141

O-RING P14

REP_PNO: 8202-011

6шт.

25

S0559353

BOLT M10X1.5X90

desc: BOULON A 6 PANS

2шт.

26

2181-1126D23

ADAPTER PFO1/2-PF3/8

desc: RACCORD ADAPTATEUR

2шт.

27

2420-9325

VALVE;BRAKE SUPPLY

SERIAL: 98-2241

1шт.

27

2420-9325A

VALVE;BRAKE SUPPLY

SERIAL: 2242

1шт.

28

S0511853

BOLT M10X1.5X20

desc: BOULON A 6 PANS

6шт.

29

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

8шт.

30

2195-3928

BRACKET

desc: SUPPORT

1шт.

31

2423-1344

BLOCK

desc: BLOC

2шт.

32

2181-1938D1

ADAPTER 2-PF3/8

desc: RACCORD ADAPTATEUR

2шт.

34

2460-9402

ACCUMULATOR 0.7L

ICA: Y

2шт.

34

2460-9034

ACCUMULATOR 0.75L

desc: RESERVOIR

2шт.

35

2184-1036D3

HOSE(S-90)3/8-650L

desc: TUYAU FLEXIBLE

2шт.

37

S8000111

O-RING P11

REP_PNO: 8202-009

1шт.

38

2181-2180

ADAPTER PF1/4

desc: RACCORD ADAPTATEUR

1шт.

39

S8180211

RING;SEAL PF1/4

desc: BAGUE

1шт.

40

2549-9093

SWITCH 65BAR

desc: INTERRUPTEUR

1шт.
