Запчасти Doosan Daewoo AIRCONDITIONER BODY PARTS

-

2920-1041

COOLER & HEATER ASS'Y

desc: CLIMATISATION

1шт.

1

2208-6010

COMPRESSOR ASS'Y 24V B-TYPE

SERIAL: 1-460

1шт.

1

2208-6010A

COMPRESSOR ASS'Y 24V B-TYPE

SERIAL: 461-1386

1шт.

1

2208-6010B

COMPRESSOR ASS'Y 24V B-TYPE

SERIAL: 1387

1шт.

2

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

2шт.

3

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

4

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

2шт.

5

2185-1370A

HOSE;COMPRESSOR

desc: TUYAU FLEXIBLE COMPRESSEUR

1шт.

6

S2212261

BOLT;SOCKET M10X1.5X35

SERIAL: 1-242

3шт.

6

S2112361

BOLT;SOCKET M10X1.5X35

SERIAL: 243

3шт.

7

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

3шт.

8

S5020603

WASHER;PLAIN M10

desc: RONDELLE PLATE

3шт.

9

2520-6003

CONDENSER ASS'Y

desc: CONDENSEUR

1шт.

10

2195-3700A

BRACKET;CONDENSER(L.H)

SERIAL: 1-90

1шт.

10

2195-3700B

BRACKET;CONDENSER(L.H)

SERIAL: 91

1шт.

11

2195-3701A

BRACKET;CONDENSER(R.H)

SERIAL: 1-90

1шт.

11

2195-3701B

BRACKET;CONDENSER(R.H)

SERIAL: 91

1шт.

12

S0553553

BOLT M6X1.0X45

desc: BOULON A 6 PANS

4шт.

13

S5102303

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

6шт.

14

S5010313

WASHER;PLAIN M6

desc: RONDELLE PLATE

6шт.

15

S4012333

NUT M6X1.0

desc: ECROU M6X1.0

4шт.

16

2185-1369D3

HOSE;LIQUID(2) L2500

desc: TUYAU FLEXIBLE

1шт.

17

2185-1371D1

HOSE;LIQUID(1) L800

desc: TUYAU FLEXIBLE

1шт.

18

2204-6032

RECEIVER DRIER

desc: RESERVOIR DESSICATEUR

1шт.

19

2514-6001

HOLDER;R/D

desc: SUPPORT RESERVOIR DESSICATEUR

1шт.

20

S0504853

BOLT M6X1.0X20

desc: BOULON A 6 PANS

4шт.

21

2920-9031

UNIT;AIR HANDLING DC 24V

SERIAL: 1-1386

1шт.

21

2920-9031B

UNIT;AIR HANDLING DC 24V

SERIAL: 1387

1шт.

22

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

4шт.

23

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

24

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

4шт.

31

2124-1084D3

CLIP;BAND 250L

desc: ATTACHE

10шт.

32

2195-2712

BRACKET;R/D HOLDER

desc: SUPPORT

1шт.

33

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

5шт.

34

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

5шт.

35

2195-3491B

BRACKET;COMPRESSOR

SERIAL: 3

1шт.

36

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

6шт.

37

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

38

2543-9027

CONTROLLER;AIRCON

desc: COMMANDE DEMARREUR

1шт.

39

S3450583

SCREW M5X0.7X12

desc: VIS

2шт.

40

S5100103

WASHER;SPRING M4

desc: RONDELLE ELASTIQUE

2шт.

41

2107-1018A

PULLEY ASS'Y;IDLE

SERIAL: 1-90

1шт.

41

2107-1018B

PULLEY ASS'Y;IDLE

SERIAL: 91

1шт.

41

2107-1018C

PULLEY ASS'Y;IDLE

ICA: P

1шт.

41

2107-1018E

PULLEY ASS'Y;IDLE

SERIAL: 3181

1шт.

41-1

2107-1017

PULLEY;IDLE

SERIAL: 1-3180

1шт.

41-1

2107-1017A

PULLEY;IDLE

SERIAL: 3181

1шт.

41-4

2114-1670

SPACER

SERIAL: 1-3180

1шт.

41-4

2114-1670A

SPACER

SERIAL: 3181

1шт.

41-5

S6003230

BEARING

SERIAL: 1-3180

1шт.

41-5

S6006230

BEARING

SERIAL: 3181

1шт.

41-10

2114-1669

SPACER

SERIAL: 1-3180

1шт.

41-10

2114-1669A

SPACER

SERIAL: 3181

1шт.

42

S0559153

BOLT M10X1.5X85

desc: BOULON A 6 PANS

2шт.

43

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

44

2549-1132D2

SWITCH;AIR CON

desc: INTERRUPTEUR

1шт.

45

2106-1016D4

V-BELT B1300

SERIAL: 1-90

1шт.

45

2106-1017D1

V-BELT 1325L

SERIAL: 91

1шт.

52

2124-9006

CLIP

desc: CLIP

4шт.

53

2191-1374D12

PLATE

desc: PLAQUE

4шт.

54

2180-1219

WASHER;SEAL

desc: RONDELLE D'ETANCHEITE

2шт.
