Запчасти Doosan Daewoo TRAVEL PIPING TRACK PARTS

-

2400-1796A

PIPING;PROPELLING ASS'Y

SC: D

-2шт.

1

2184-1222D18

HOSE 1650L

SERIAL: 1-505

2шт.

1

2184-1222D31

HOSE 1650L

SERIAL: 506

2шт.

2

2184-1222D19

HOSE 1700L

SERIAL: 1-505

2шт.

2

2184-1222D32

HOSE 1700L

SERIAL: 506

2шт.

3

2181-9081

FLANGE;SPLIT

desc: BRIDE

8шт.

4

S2215361

BOLT;SOCKET M12X1.75X35

SERIAL: 1-711

16шт.

4

S2215366

BOLT;SOCKET M12X1.75X35

SERIAL: 712

16шт.

5

2180-1026D19

O-RING

desc: JOINT TORIQUE

4шт.

6

2181-4133D5

ADAPTER PF3/4-UNF1 3/16

desc: RACCORD ADAPTATEUR

4шт.

7

S8000241

O-RING

desc: JOINT TORIQUE

4шт.

8

S8030121

O-RING

desc: JOINT TORIQUE

4шт.

9

2184-1060D70

HOSE PF1/2-1700L

desc: TUYAU FLEXIBLE

2шт.

10

2184-1060D144

HOSE PF1/4-2000L

desc: TUYAU FLEXIBLE

2шт.

11

2181-2281D10

TEE 3-PF1/2

desc: TE

1шт.

12

S8000181

O-RING

desc: JOINT TORIQUE

3шт.

13

2181-1126D6

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

14

2181-1126D14

ADAPTER

desc: RACCORD ADAPTATEUR

3шт.

15

S8000111

O-RING

desc: JOINT TORIQUE

3шт.

16

2181-4125

TEE

desc: TE

1шт.

17

2160-1322D2

BUSHING;RUBBER

desc: GARNISSAGE CAOUTCHOUC

4шт.
