Запчасти Doosan Daewoo BUCKET-0.35§© OPTION PARTS

-

2704-1380B

BUCKET SUB ASS'Y-0.35§©

SERIAL: 1-23

1шт.

-

2704-1380C

BUCKET SUB ASS'Y-0.35§©

SERIAL: 24-175

1шт.

-

2704-1380E

BUCKET SUB ASS'Y-0.35§©

SERIAL: 176-280

1шт.

-

2704-1380G

BUCKET SUB ASS'Y-0.35§©

SERIAL: 281-1433

1шт.

-

2704-1380I

BUCKET SUB ASS'Y-0.35§©

SERIAL: 1434

1шт.

1

-

BUCKET-0.35§©(OPT.)

SC: D

1шт.

1-1

2713-1222

ADAPTER;TOOTH

SERIAL: 1-23

4шт.

1-1

2713-1222A

ADAPTER;TOOTH

SERIAL: 24

4шт.

2

2713-1221

POINT;TOOTH

SERIAL: 1-23

4шт.

2

2713-1221A

POINT;TOOTH

SERIAL: 24

4шт.

3

2705-1022

PIN;LOCKING

desc: GOUPILLE DE BLOCAGE

4шт.

4

2114-1859

WASHER;LOCKING

desc: RONDELLE

4шт.

5

2713-1228

CUTTER;SIDE(R)

desc: COIN DE GODET DROIT

1шт.

6

2713-1229

CUTTER;SIDE(L)

desc: COIN DE GODET GAUCHE

1шт.

7

S0570061

BOLT

desc: BOULON A 6 PANS

8шт.

8

S4013133

NUT

desc: ECROU

8шт.

9

S5103101

WASHER;SPRING

SERIAL: 1-175

8шт.

9

2114-9012

WASHER;HARDEN

SERIAL: 176

8шт.
