Запчасти Doosan Daewoo BOOM PIPING-BOOM 4.6M(ONE WAY) OPTION PARTS

-

2400-2168

BOOM PIPING(BOOM 4.6m)

SERIAL: 1-597

-2шт.

1

2140-1671

PIPE

desc: TUYAU

2шт.

2

2140-1713

PIPE

desc: TUYAU

2шт.

3

2184-1196D79

HOSE PF3/4-800L

desc: TUYAU FLEXIBLE

2шт.

4

2181-1950D15

PLUG

desc: BOUCHON

2шт.

5

S8000231

O-RING

desc: JOINT TORIQUE

4шт.

6

S8030121

O-RING

desc: JOINT TORIQUE

6шт.

7

2124-1026D2

CLAMP;PIPE

desc: FIXATION DE TUYAU

8шт.

8

S0560753

BOLT M12X1.75X50

desc: BOULON A 6 PANS

12шт.

9

S5102703

WASHER;SPRING

desc: RONDELLE ELASTIQUE

12шт.

10

2124-1694

CLAMP;PIPE

desc: FIXATION DE TUYAU

2шт.

11

2161-2250A

RUBBER

desc: CAOUTCHOUC

4шт.

12

2420-9627

VALVE;RELIEF

desc: CLAPET DE DECHARGE

1шт.

13

2181-2819

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

14

S8000291

O-RING

desc: JOINT TORIQUE

2шт.

15

2181-4133D12

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

16

2184-1197D51

HOSE PF3/4-950L

desc: TUYAU FLEXIBLE

1шт.

17

2181-2627D1

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.
