Запчасти Doosan Daewoo TRACK SHOE ASSY-950-(S130LC-V) OPTION PARTS

1

9273-6004D3

TRACK SHOE ASS'Y950 (LH)

desc: ENSEMBLE CHENILLE

2шт.

1

9273-6004

TRACK SHOE ASS'Y950 (RH)

desc: ENSEMBLE CHENILLE

2шт.

1-1

9272-6017

LINK;TRACK (R.H) (LC)

desc: . MAILLON

45шт.

1-2

9272-6016

LINK;TRACK (R.H) (SC)

desc: . MAILLON

45шт.

1-3

9123-6009

PIN;TRACK (SC)

desc: . GOUJON

45шт.

1-4

9110-6004

BUSHING;TRACK (LC)

desc: . MANCHON

45шт.

1-5

9123-6010

PIN;MASTER

desc: . GOUPILLE

1шт.

1-6

9110-6005

BUSHING;MASTER

desc: . DOUILLE

1шт.

1-7

9114-6006

SPACER

desc: . DOUILLE D'ESPACEMENT

2шт.

1-8

9272-6017

LINK;MASTER(R.H)

desc: . MAILLON PRINCIPAL(DROIT)

1шт.

1-9

9272-6016

LINK;MASTER(L.H)

desc: . MAILLON PRINCIPAL(GAUCHE)

1шт.

1-11

9120-6006D12

BOLT5/8-18UNF

desc: . BOULON A 6 PANS

184шт.

1-12

9121-6005D11

NUT 5/8-18 UNF

desc: . ECROU

184шт.

1-13

9273-9003

SHOE 950mm(LH)

desc: . SABOT

46шт.

1-13

9273-9004

SHOE 950mm(RH)

desc: . SABOT

46шт.

2

9195-1124

STEP;BRACKET

SERIAL: 1-50180

4шт.

2

9195-1124

STEP;BRACKET

SERIAL: 50491

4шт.

2

9195-1132

STEP;BRACKET

SERIAL: 50181-50490

4шт.

3

S0515353

BOLT M12X35 8.8

desc: BOULON A 6 PANS

16шт.

4

S5102703

WASHER; SPRING

desc: RONDELLE GROWER

16шт.

5

9272-6014D2

LINK ASS'Y

desc: ENSEMBLE MAILLON DE CHAINE

2шт.
