Запчасти Doosan Daewoo BOOM HOLDING VALVE OPTION PARTS

-

2400-1764

PIPING;BOOM HOLDING V/V

SERIAL: 161-220

1шт.

1

2420-9029

VALVE;BOOM HOLDING

desc: VANNE

1шт.

1-1

-

BLOCK

desc: . BLOC

1шт.

1-2

-

BOLT

desc: . BOULON A 6 PANS

1шт.

2

2423-1466

BLOCK

desc: BLOC

1шт.

3

2197-1425

SUPPORT

desc: SUPPORT

1шт.

4

2423-1465

BLOCK

desc: BLOC

1шт.

5

2140-1208

PIPE

desc: TUYAU

1шт.

6

2184-1197D54

HOSE(90ўЄ-ST)

desc: TUYAU FLEXIBLE

1шт.

7

2184-1061D47

HOSE(90ўЄ-90ўЄ)

desc: TUYAU FLEXIBLE

1шт.

8

2184-1096D14

HOSE(90ўЄ-90ўЄ)

desc: TUYAU FLEXIBLE

1шт.

9

2184-1076D5

HOSE(135ўЄ-90ўЄ)

desc: TUYAU FLEXIBLE

1шт.

10

2181-2604

TEE 2-PF1/4.PFO1/4

desc: TE

1шт.

11

S8000111

O-RING PF1/4

REP_PNO: 8202-009

4шт.

12

2181-1951D5

TEE PFO1/2 2-PF1/2

desc: TE

1шт.

13

S8000181

O-RING PF1/2

REP_PNO: 8202-014

2шт.

14

2181-1951D14

TEE PFO1/4.PF1/4.PF3/8

desc: TE

1шт.

15

S5010613

WASHER;PLAIN

desc: RONDELLE PLATE

4шт.

16

2181-1126D6

ADAPTER PFO1/2.PF1/2

desc: RACCORD

1шт.

17

S2212461

BOLT;SOCKET M10

desc: BOULON A 6 PANS CREUX

4шт.

18

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

8шт.

19

S0512353

BOLT M10X1.5X5

desc: BOULON A 6 PANS

4шт.

20

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

21

S0515253

BOLT M12

desc: BOULON A 6 PANS

2шт.

22

S5020713

WASHER M12

desc: RONDELLE

2шт.

23

2181-4133D5

ADAPTER PFO3/4. UNF 1 3/16-12

desc: RACCORD

1шт.

24

S8000241

O-RING PFO3/4

desc: JOINT TORIQUE

1шт.

25

S8030121

O-RING 1 3/16-12

desc: JOINT TORIQUE

1шт.

26

2181-1126D14

ADAPTER PFO1/4.PF1/4

desc: RACCORD

1шт.

27

2181-1702D3

ELBOW PFO1/4.PF3/8

desc: RACCORD

1шт.

28

2197-1429

BRACKET

desc: SUPPORT

1шт.

29

2180-1026D2

O-RING SAE 3/4

desc: JOINT TORIQUE

1шт.

30

S2212861

BOLT;SOCKET M10

desc: BOULON A 6 PANS CREUX

4шт.

31

S5110701

WASHER;SPRING M12

REP_PNO: 8131-009

2шт.
