Запчасти Doosan Daewoo REDUCTION GEAR HYDRAULIC PARTS

-

630006D01

GEAR;REDUCTION

SERIAL: 1-56

1шт.

1

6323700643

CASING

desc: BOITIER

1шт.

2

6333701066

SHAFT;DRIVE

desc: ARBRE MOTEUR

1шт.

3

6333701065

GEAR

desc: COURONNE DENTEE

1шт.

4

6343700891

GEAR NO.2 PLANET

desc: PIGNON PLANETAIRE

4шт.

5

6343700889

GEAR NO.2 SUN

desc: PIGNON PRINCIPAL

1шт.

6

6343700890

GEAR NO.1 PLANET

desc: PIGNON PLANETAIRE

3шт.

7

6343700888

GEAR NO.1 SUN

desc: PIGNON PRINCIPAL

1шт.

8

6324120-0006

CARRIER NO.2

desc: SUPPORT

1шт.

9

6333701067

CARRIER NO.1

desc: PORTE-SATELLITES N1

1шт.

10

6343700565

PIN NO.1

desc: GOUPILLE

4шт.

11

6353700710

PIN NO.1

desc: GOUPILLE

3шт.

12

6353700601

WASHER 1;THRUST

desc: RONDELLE BUTEE

3шт.

13

PAS30

PLATE;SIDE

desc: PLAQUE LATERALE

9шт.

14

6353700603

WASHER 3;THRUST

desc: RONDELLE BUTEE

1шт.

15

6343700401

BAR;LEVEL

desc: BARRE

1шт.

16

6353700406

PIPE

desc: CONDUITE

1шт.

17

6353800449

PIN

desc: BROCHE

2шт.

18

P22314

BRG.SPHERICAL ROLLER

desc: ROULEMENT A SPHERIQUE

1шт.

19

PNJ313

BEARING;ROLLER

desc: ROULEMENT A ROULEAUX

1шт.

20

PKT303818

NEEDLE;CAGE

desc: ROULEMENT A AIGUILLES

3шт.

21

OSBM12110

SCREW;HEX

desc: VIS

10шт.

22

PTC709513N

SEAL;OIL

desc: JOINT D'HUILE

1шт.

23

OBP12U

PLUG

desc: BOUCHON

1шт.

24

OBP14U

PLUG

desc: BOUCHON

2шт.

25

OSPV616

PIN;SPRING

desc: GOUPILLE ELASTIQUE

7шт.

26

OSR30

RING;SNAP

desc: BAGUE ELASTIQUE

4шт.

27

OSR62

RING;SNAP

desc: BAGUE ELASTIQUE

1шт.

28

6353700987

SEAL;BEARING

desc: JOINT-ENTREETOISE

1шт.
