Запчасти Doosan Daewoo REDUCTION GEAR HYDRAULIC PARTS

-

2404-9133P

GEAR;REDUCTION

SERIAL: 57-384

1шт.

1

DH04-9210-001

CASING

desc: BOITIER

1шт.

2

DH04-9210-002

SHAFT;DRIVE

desc: ARBRE MOTEUR

1шт.

3

DH04-9210-003

GEAR;RING

desc: PIGNON D'BAGUE

1шт.

4

DH04-9210-004

GEAR NO.2;PLANET

desc: PIGNON PLANETAIRE

4шт.

5

DH04-9210-005

GEAR NO.2;SUN

desc: PIGNON CENTRAL

1шт.

6

DH04-9210-006

GEAR NO.1;PLANET

desc: PIGNON PLANETAIRE

3шт.

8

DH04-9210-008

CARRIER NO.2

desc: PORTE-SATELLITES

1шт.

9

DH04-9210-009

CARRIER NO.1

desc: PORTE-SATELLITES

1шт.

10

DH04-9210-010

PIN NO.2

desc: BROCHE

4шт.

11

DH04-9210-011

PIN NO.1

desc: BROCHE

3шт.

12

DH04-9210-012

WASHER C;THRUST

desc: RONDELLE BUTEE

4шт.

13

DH04-9210-013

WASHER B;THRUST

desc: RONDELLE BUTEE

9шт.

14

DH04-9210-014

WASHER A;THRUST

desc: RONDELLE BUTEE

2шт.

15

DH04-9210-015

BAR;LEVEL

desc: BARRE

1шт.

16

DH04-9210-016

PIPE;LEVEL GAUGE

desc: TUYAU

1шт.

17

DH04-9210-017

PIN;LOCK

desc: GOUPILLE DE BLOCAGE

2шт.

18

DH04-9210-018

BEARING;SPHERICAL ROLLER

desc: ROULEMENT A ROULEAUX

1шт.

19

DH04-9210-019

BEARING;ROLLER

desc: ROULEMENT A ROULEAUX

1шт.

20

DH04-9210-020

SCREW;HEX

desc: VIS

10шт.

21

DH04-9210-021

SEAL;OIL

desc: JOINT D'HUILE

1шт.

22

DH04-9210-022

PLUG B

desc: BOUCHON

1шт.

23

DH04-9210-023

PLUG A

desc: BOUCHON

2шт.

24

DH04-9210-024

PIN;SPRING

desc: GOUPILLE ELASTIQUE

3шт.

25

DH04-9210-025

RING;RETAINER

desc: BAGUE CIRCLIPS

3шт.

26

DH04-9210-026

RING;RETAINER

desc: BAGUE CIRCLIPS

1шт.

27

DH04-9210-027

RING;RETAINER

desc: BAGUE CIRCLIPS

1шт.

28

DH04-9210-028

RING

desc: BAGUE

1шт.

29

DH04-9210-029

PIN;SPRING

desc: GOUPILLE ELASTIQUE

4шт.
