Запчасти Doosan Daewoo OIL PUMP ENGINE PARTS

-

65.05101-7014

OIL PUMP ASS'Y(NO.1-22)

desc: ENSEMBLE POMPE A HUILE

1шт.

1

65.05102-6003

OIL PUMP HOUSING ASS'Y(NO.2-4)

desc: . BOITER DE POMPE A HUILE

1шт.

2

65.05102-0018

HOUSING;OIL PUMP

desc: .. CARTER DE POMPE A HUILE

1шт.

3

65.05105-0003

SHAFT;OIL PUMP

desc: .. ARBRE

1шт.

4

65.91710-0012

RING;STOPPER

desc: .. ANNEAU DE BLOCAGE

1шт.

5

65.05103-0019

COVER;OIL PUMP

desc: . COUVERCLE

1шт.

6

06.31641-0222

BALL;STEEL 15/32

desc: . BILLE

1шт.

7

65.97601-0041

SPRING;COMPRESSION

desc: RESSORT DE COMPRESSION

1шт.

7

65.97601-0090

SPRING;COMPRESSION

desc: . RESSORT DE COMPRESSION

1шт.

8

65.91305-0007

SEAT;SPRING

desc: . POSSESSEUR

1шт.

9

06.22070-0913

PIN;SPLIT 4X30

desc: . GOUPILLE FENDUE

1шт.

10

65.05104-0002

GEAR;OIL PUMP

desc: . PIGNON DE POMPE A HUILE

1шт.

11

65.05104-6002

OIL PUMP GEAR ASS'Y

desc: . ENSEMBLE D'ENGRENAGE DE POMPE

1шт.

12

65.05104-0002

GEAR;OIL PUMP

desc: . PIGNON DE POMPE A HUILE

1шт.

13

65.05105-0003

SHAFT;OIL PUMP

desc: . ARBRE

1шт.

20

06.01013-9117

BOLT;HEX. M8X60

desc: . BOULON A 6 PANS

4шт.

21

06.16731-2107

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

4шт.

22

65.05705-6007

STRAINER ASS'Y

desc: . CREPINE

1шт.

23

06.01944-3215

BOLT ASS'Y M10X1.25X25

desc: BOULON A 6 PANS

2шт.

25

65.05207-0006

COUPLING;SLEEVE

desc: ACCOUPLEMENT

1шт.

26

65.05201-0006

GEAR;OIL PUMP DRIVE

desc: PIGNON D'ENTRAINEMENT POMPE A HUILE

1шт.

27

65.05120-0001

BUSH;DRIVE GEAR

desc: BAGUE D'ECARTEMENT

1шт.
