Запчасти Doosan Daewoo CRANK SHAFT ENGINE PARTS

-

65.02101-6018

CRANK SHAFT ASS'Y(NO.1-2)

desc: ENSEMBLE VILEBREQUIN

1шт.

1

65.02101-0045A

SHAFT;CRANK

desc: . VILEBREGUIN

1шт.

2

06.22022-3210

PIN;PARALLEL

desc: . GOUPILLE

1шт.

3

65.02115-0013

GEAR;CRANK SHAFT

desc: PIGNON DE VILEBREQUIN

1шт.

4

65.91501-0006

KEY;SLIDING

desc: CLAVETTE

1шт.

5

65.02120-0002

RING;OIL THROWER

desc: BAGUE

1шт.

6

65.90501-0006

NUT

desc: ECROU

1шт.

7

65.93020-0015

BUSH;TAPER

desc: COUSSINET

1шт.

10

65.02301-5055

FLYWHEEL ASS'Y(NO.11-12)

desc: ENSEMBLE VOLANT

1шт.

11

65.02301-0203

WHEEL;FLY

desc: . VOLANT

1шт.

12

65.02310-0006

GEAR;STARTING RING

desc: . COURONNE DENTEE DEMARREUR

1шт.

13

06.01494-4506

BOLT;HEX. M16X1.5X35

desc: BOULON A 6 PANS

6шт.

14

65.90701-0021

WASHER

desc: RONDELLE PLATE

1шт.

20

65.02401-6161

CONNECTING ROD ASS'Y(NO.21-23)

desc: ENSEMBLE DE BIELLE

6шт.

21

65.02401-0161

ROD;CONNECTING

desc: . BIELLE

6шт.

22

65.02405-1060

BUSH

desc: . COUSSINET

6шт.

23

65.02411-0006

BOLT

desc: . BOULON A 6 PANS

12шт.

24

65.02410-6083

METAL

desc: PALIER

6шт.

25

65.02501-0152

PISTON

desc: PISTON

6шт.

26

65.02503-0099

RING;TOP

desc: SEGMENT COUP DE FEU

6шт.

27

65.02503-0098

RING;SECOND

desc: SEGMENT DE COMPRESSION

6шт.

28

65.02503-0096

RING;OIL

desc: SEGMENT RACLEUR

6шт.

29

65.02502-0002

PIN;PISTON

desc: AXE DE PISTON

6шт.

30

06.29020-0121

RING;RETAINING

desc: BAGUE CIRCLIPS

12шт.

31

65.02601-5015

PULLEY;V-BELT

desc: POULIE DE COURROIE TRAPEZOIDALE

1шт.
