Запчасти Doosan Daewoo COOLING SYSTEM ENGINE PARTS

1

65.06601-0012

FAN;COOLING

desc: VENTILATEUR

1шт.

2

65.06611-0099

FLANGE;FAN

desc: BRIDE

1шт.

3

65.06611-0089

FLANGE;FAN

desc: BRIDE

1шт.

4

06.01013-9124

BOLT;HEX. M8X95

desc: BOULON A 6 PANS

4шт.

5

06.01923-3119

BOLT ASS'Y M8X40

desc: BOULON A 6 PANS

4шт.

6

06.15010-2311

WASHER;PLAIN

desc: RONDELLE PLATE

4шт.

7

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

8

06.11063-8214

NUT;HEX. M8

desc: ECROU

4шт.

9

65.96801-0095

V-BELT L=1260

desc: COURROIE

1шт.

10

06.01493-4214

BOLT;HEX. M10X1.25X75

desc: BOULON A 6 PANS

1шт.

11

06.01943-3221

BOLT;HEX. M10X1.25X50

desc: BOULON A 6 PANS

2шт.

12

06.01493-4206

BOLT;HEX. M10X1.25X35

desc: BOULON A 6 PANS

1шт.

13

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

14

65.06503-0076

PULLEY;V-BELT

desc: POULIE DE COURROIE TRAPEZOIDALE

1шт.

15

65.06901-0002

GASKET

desc: JOINT

1шт.

16

65.06404-0003

HOUSING ASS'Y

desc: ENSEMBLE CARTER

1шт.

17

65.06402-5004

ELEMENT;THERMOSTAT

desc: ELEMENT FILTRANT

1шт.

18

65.06405-0012

OUTLET;WATER

desc: SORTIE A EAU

1шт.

19

06.01923-3114

BOLT ASS'Y

desc: BOULON A 6 PANS

3шт.

22

06.01493-4217

BOLT;HEX. M10X1.25X95

desc: BOULON A 6 PANS

3шт.

23

06.01733-4211

BOLT;HEX. M10X1.25X35

desc: BOULON A 6 PANS

3шт.

24

06.16044-0211

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.

26

06.08092-2405

SCREW;PLUG M16X1.5

desc: BOUCHON A VIS

1шт.

27

06.56190-0709

RING;SEAL A16X22

desc: BAGUE D'ETANCHEITE

1шт.

28

66.27435-6007

SWITCH;THERMO 10C

desc: CONTACTEUR THERMO

1шт.

29

65.06406-2002

PIPE;THERMOSTAT

desc: TUYAU

1шт.

30

65.96301-0045

HOSE;RUBBER

desc: FLEXIBLE D'EAU

1шт.

31

06.67020-0106

CLAMP;HOSE

desc: COLLIER

2шт.

32

65.06904-0004

GASKET

desc: JOINT

1шт.

33

65.06904-0003

PACKING

desc: JOINT

1шт.

34

65.05601-7056

OIL COOLER ASS'Y

desc: ENSEMBLE REFROIDISSEUR D'HUILE

1шт.

35

06.01923-3124

BOLT ASS'Y

desc: BOULON A 6 PANS

1шт.

36

06.01923-3120

BOLT ASS'Y

desc: BOULON A 6 PANS

12шт.

37

06.01923-3115

BOLT ASS'Y M8X25

desc: BOULON A 6 PANS

15шт.

38

06.01923-3113

BOLT ASS'Y

desc: BOULON A 6 PANS

2шт.

41

65.05902-0005

GASKET

desc: JOINT

1шт.
