Запчасти Doosan Daewoo PILOT PIPING(5-1) BODY PARTS

-

2400-1880

PILOT PIPING

SERIAL: 385

-2шт.

3

S0505053

BOLT M6X1.0X25

desc: BOULON A 6 PANS

4шт.

4

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

4шт.

11

2420-9417

VALVE;REMOCON(R.H)

SERIAL: 385-491

1шт.

11

2420-9544

VALVE;REMOCON(R.H)

SERIAL: 492

1шт.

13

2621-2752

PLATE

desc: PLAQUE CAOUTCHOUC

1шт.

28

2181-1951D1

TEE PF1/4(O)XPF1/4XPF1/4

desc: TE

2шт.

29

S8000111

O-RING P11

REP_PNO: 8202-009

17шт.

30

2181-1126D14

ADAPTER PFO 1/4. PF 1/4

desc: RACCORD

6шт.

31

2181-1702D4

ELBOW(90) PFO. PF 1/4

desc: RACCORD

1шт.

36

2181-2419D1

ELBOW(90) PFO.PF 1/4 45ЎЈ

desc: RACCORD

2шт.

50

2184-1045D61

HOSE 1/4.400L

desc: TUYAU FLEXIBLE

1шт.

53

2184-1129D20

HOSE 1/4. 550L

desc: TUYAU FLEXIBLE

1шт.

67

2184-1046D171

HOSE 1/4. 380L

desc: TUYAU FLEXIBLE

1шт.

72

2184-1060D124

HOSE 1/4. 800L

desc: TUYAU FLEXIBLE

1шт.

74

2184-1249D31

HOSE 1/4. 1250L

desc: TUYAU FLEXIBLE

2шт.

78

2184-1249D13

HOSE 1/4. 2650L

desc: TUYAU FLEXIBLE

2шт.

91

2184-1249D14

HOSE 1/4. 2850L

desc: TUYAU FLEXIBLE

1шт.

93

2184-1249D13

HOSE 1/4. 2650L

desc: TUYAU FLEXIBLE

1шт.

104

2181-2604

TEE PFO1/4.2-PF1/4

desc: TE

1шт.

105

2420-9377A

VALVE;SHOCKLESS Ґх1.2

desc: VANNE

2шт.

110

2181-1126D118

ADAPTER PFO1/4-PF1/4

desc: RACCORD

1шт.

112

2181-1126D89

ADAPTER PFO1/4-PF3/8

desc: RACCORD

4шт.

114

2184-1036D167

HOSE PF1/4.650L

desc: TUYAU FLEXIBLE

1шт.
