Запчасти Doosan Daewoo LOW PRESSURE PIPING(1) BODY PARTS

-

2400-1641

LOW PRESSURE PIPING

desc: CONDUITES BASSE PRESSION

1шт.

1

2185-1002D29

HOSE;SUCTION 240L

SERIAL: 0001-0008

1шт.

1

2185-1002D69

HOSE;SUCTION 630L

SERIAL: 0009

1шт.

1

2185-1002D100

HOSE;SUCTION 590L

SERIAL: 301

1шт.

2

2183-4629A

PIPE;SUCTION

desc: TUBE D'ASPIRATION

1шт.

7

S8010751

O-RING

desc: JOINT TORIQUE

1шт.

9

2184-1197D30

HOSE 3/4 600L

desc: TUYAU FLEXIBLE

1шт.

12

S8450066

CLAMP;HOSE

desc: COLLIER

4шт.

13

2181-2047

PLUG M10X1.0

desc: BOUCHON

1шт.

16

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

4шт.

21

S0561753

BOLT M12X1.75X100

desc: BOULON A 6 PANS

4шт.

31

S8030121

O-RING 1 3/16-12

desc: JOINT TORIQUE

2шт.

32

2181-2294D2

ELBOW ORS 3/4

desc: COUDE

1шт.

33

S8000241

O-RING 3/4

desc: JOINT TORIQUE

2шт.

48

2181-4133D5

ADAPTER PFO3/4. UNF 1 3/16-12

desc: RACCORD

1шт.
