Запчасти Doosan Daewoo HEATER BOX BODY PARTS

-

2920-1040E

BOX;HEATER

SERIAL: 0001-0008

1шт.

-

2920-1040J

BOX;HEATER

SERIAL: 0009

1шт.

1

2195-3715E

SUPPORT

desc: SUPPORT

1шт.

2

2621-2643E

COVER

desc: COUVERCLE

1шт.

3

2621-2644B

COVER

desc: COUVERCLE

1шт.

4

2621-2693C

COVER

desc: COUVERCLE

1шт.

5

2191-3235A

PLATE

desc: PLAQUE

2шт.

6

2415-9003

NOZZLE;AIRCON

desc: BUSE

4шт.

7

S0504453

BOLT M6X1.0X12

desc: BOULON A 6 PANS

8шт.

8

S5000313

WASHER;PLAIN M6

desc: RONDELLE PLATE

8шт.

9

S0508652

BOLT M8X1.25X16

desc: BOULON A 6 PANS

9шт.

10

S5010511

WASHER;PLAIN M8

desc: RONDELLE PLATE

9шт.

11

2920-1040-11

CUSHION;RUBBER

desc: SUSPENSION

2шт.

12

2920-1040-12

CUSHION;RUBBER

desc: SUSPENSION

4шт.

13

2124-1360

CLIP;CODE

desc: ATTACHE

2шт.

14

2190-2049

PLATE;NAME

desc: PLAQUE SIGNALETIQUES

1шт.

15

2621-2774A

COVER

desc: COUVERCLE

1шт.

16

2621-2642A

COVER

desc: COUVERCLE

1шт.

17

S0504453

BOLT;SOCKET M6X1.0X12

desc: BOULON A 6 PANS

4шт.

18

S5110303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

4шт.

19

S5020313

WASHER;PLAIN M6

desc: RONDELLE PLATE

4шт.

20

2158-1017D1

HOSE Ґх54

desc: TUYAU FLEXIBLE

5шт.

21

S8450044

CLAMP;HOSE

desc: COLLIER

9шт.

22

S0511852

BOLT M10X1.5X20

desc: BOULON A 6 PANS

4шт.

23

S5102601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

24

S5010611

WASHER;PLAIN M10

desc: RONDELLE PLATE

4шт.

25

S3644193

SCREW;TAPPING M3X10

desc: VIS TARAUDEUSE

2шт.

26

2415-9005

NOZZLE;SPINDLE

desc: INJECTEUR

1шт.

27

2125-1081

CASE;UPPER

desc: CARTER

1шт.

28

2125-1082

CASE;LOWER

desc: CARTER

1шт.

29

S3640523

SCREW;TAPPING M5X10

desc: VIS TARAUDEUSE

4шт.

30

2161-1953

PLATE

desc: PLAQUE

1шт.

31

2124-1084D3

CLIP;BAND

desc: ATTACHE

1шт.

32

2124-1744

RUBBER DF

desc: CAOUTCHOUC

1шт.

33

2161-1219

GROMMET

desc: GARNISSAGE CAOUTCHOUC

1шт.

37

2621-3023

COVER

SERIAL: 0009

1шт.
