Запчасти Doosan Daewoo AIR CONDITIONER BODY PARTS

-

2920-1053

COOLER & HEATER ASS'Y

desc: REFRIGERATION

-2шт.

1

2208-6010A

COMPRESSOR V-5. B-TYPE

SERIAL: 1-165

1шт.

1

2208-6010B

COMPRESSOR V-5. B-TYPE

SERIAL: 166

1шт.

2

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

2шт.

3

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

4

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

2шт.

5

2185-1370A

HOSE;COMPRESSOR

desc: TUYAU FLEXIBLE COMPRESSEUR

1шт.

6

2180-1219

WASHER;SEAL

desc: RONDELLE D'ETANCHEITE

2шт.

7

S2212361

BOLT;SOCKET M10X1.5X35

desc: BOULON A 6 PANS CREUX

3шт.

8

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

3шт.

9

S5020603

WASHER;PLAIN M10

desc: RONDELLE PLATE

3шт.

10

2520-6003

CONDENSER ASS'Y

desc: ENSEMBLE COMPRESSEUR

1шт.

11

2197-1066

BRACKET;CONDENSER(R)

desc: SUPPORT

1шт.

12

2197-1067

BRACKET;CONDENSER(L)

desc: SUPPORT

1шт.

13

S0553553

BOLT M6X1.0X45

desc: BOULON A 6 PANS

4шт.

14

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

6шт.

15

S5010313

WASHER;PLAIN M6

desc: RONDELLE PLATE

6шт.

16

S4012333

NUT M6X1.0

desc: ECROU

4шт.

17

2185-1369D7

HOSE;LIQUID(1) L400

SERIAL: 0001-0047

1шт.

17

2185-1369D14

HOSE;LIQUID(1) L450

SERIAL: 0048

1шт.

18

2185-1369D3

HOSE;LIQUID(2) L2500

desc: TUYAU FLEXIBLE LIQUIDE(2)

1шт.

19

2204-6032

RECEIVER DRIER

desc: RESERVOIR DESSICATEUR

1шт.

20

2514-6001

HOLDER;RECEIVER DRIER

desc: POSSESSEUR

1шт.

21

S0504453

BOLT M6X1.0X12

SERIAL: 1-315

2шт.

21

S0504653

BOLT M6X1.0X16

SERIAL: 316

2шт.

22

2195-2712

BRACKET;R/D HOLDER

desc: SUPPORT

1шт.

23

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

2шт.

24

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

25

2195-2707B

BRACKET;COMPRESSOR

desc: SUPPORT

1шт.

26

S0512353

BOLT M10X1.5X35

SERIAL: 0001-0115

1шт.

26

S0712373

BOLT M10X1.5X35

SERIAL: 0116

1шт.

27

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.

28

2107-6002

PULLEY;IDLE

desc: ENSEMBLE POULIE FOU

1шт.

29

S0559253

BOLT M10X1.5X85

SERIAL: 0001-0115

2шт.

29

S0759273

BOLT M10X1.5X85

SERIAL: 0116

2шт.

30

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

31

2106-1016D1

V-BELT B-1125

SERIAL: 1-384

1шт.

31

2106-1021D1

V-BELT B-1125

SERIAL: 385

1шт.

32

2920-9031

AIR HANDLING UNIT

SERIAL: 1-21

1шт.

32

2920-9031A

AIR HANDLING UNIT

SERIAL: 22-175

1шт.

32

2920-9031B

AIR HANDLING UNIT

SERIAL: 176

1шт.

33

2191-1374D12

PLATE

SERIAL: 1-315

4шт.

33

2191-1374D12

PLATE

SERIAL: 316

2шт.

34

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

4шт.

35

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

36

2114-1058D29

WASHER Ґх26XҐх9

desc: RONDELLE PLATE

4шт.

37

2549-1132D2

SWITCH;AIRCON

desc: INTERRUPTEUR

1шт.

38

2543-9027

CONTROLLER;AIRCON

desc: MODULE DE COMMANDE

1шт.

39

S3450583

SCREW M4X0.7X12

desc: VIS

2шт.

40

S5100103

WASHER;SPRING M4

desc: RONDELLE ELASTIQUE

2шт.

47

2124-1084D3

CLIP;BAND L250

desc: ATTACHE

15шт.

48

S4012633

NUT M10X1.5

SERIAL: 316

1шт.

49

S5010613

WASHER;PLAIN M10

SERIAL: 316

1шт.
