Запчасти Doosan Daewoo CONTROL VALVE(1) TRACK PARTS

1

07307-00000

CONTROL VALVE ASS'Y

SERIAL: 1-296

1шт.

2

06241-06000

INLET SECTION ASS'Y

desc: TIROIRS DE COMMANDE

1шт.

3

06470-05300

BLOCK ASS'Y-TRAVEL(L)

desc: BLOC

1шт.

4

07307-05200

BLOCK ASS'Y

desc: BLOC

1шт.

5

07307-05000

BLOCK ASS'Y-ARM

desc: BLOC

1шт.

6

07307-05100

BLOCK ASS'Y-PTO

desc: BLOC

1шт.

7

06470-06100

BLOCK ASS'Y-TRAVEL(R)

desc: BLOC

1шт.

8

07307-05400

BLOCK ASS'Y-BUCKET

desc: BLOC

1шт.

9

07307-05300

BLOCK ASS'Y-BOOM

desc: BLOC

1шт.

10

06470-06300

BLOCK ASS'Y

desc: BLOC

1шт.

11

06470-05600

BLOCK ASS'Y-ARM SWING

desc: BLOC

1шт.

12

07307-05500

BLOCK ASS'Y-DOZER

desc: BLOC

1шт.

13

06470-05800

BLOCK ASS'Y-SWING

desc: BLOC

1шт.

14

06470-06200

INLET SECTION ASS'Y

desc: TIROIRS DE COMMANDE

1шт.

15

86781-00017

O-RING

desc: JOINT TORIQUE

24шт.

16

86781-00030

O-RING

desc: JOINT TORIQUE

11шт.

17

86781-00031

O-RING

desc: JOINT TORIQUE

1шт.

18

06470-05000

MAIN RELIEF V/V ASS'Y(P1.P2)

desc: ENSEMBLE CLAPET DECHARGE

2шт.

19

86711-02018

O-RING

desc: JOINT TORIQUE

2шт.

20

86711-02012

O-RING

desc: JOINT TORIQUE

2шт.

21

06204-0500A

COMBINATION VALVE ASS'Y

desc: VANNE

4шт.

22

86711-02016

O-RING

desc: JOINT TORIQUE

1шт.

23

86711-01010

O-RING

desc: JOINT TORIQUE

1шт.

24

06470-05200

PORT RELIEF VALVE ASS'Y

desc: PORT

1шт.

25

86711-02016

O-RING

desc: JOINT TORIQUE

1шт.

26

86711-01010

O-RING

desc: JOINT TORIQUE

1шт.

27

06212-06400

SUCTION CHECK VALVE ASS'Y

desc: VANNE

1шт.

28

86711-02016

O-RING

desc: JOINT TORIQUE

1шт.

29

86711-01010

O-RING

desc: JOINT TORIQUE

1шт.

30

87143-00002

PLUG

desc: BOUCHON

3шт.

31

87143-00005

PLUG

desc: BOUCHON

1шт.

32

05235-10600

ROD;TIE

desc: TIGE

4шт.

33

83203-10080

NUT

desc: ECROU

8шт.

34

06470-05100

MAIN RELIEF V/V ASS'Y(P3)

desc: ENSEMBLE CLAPET DECHARGE

1шт.
