Запчасти Doosan Daewoo HYDRAULIC PIPING(3) BODY PARTS

-

2400-7088

HYDRAULIC PIPING

SERIAL: 1-354

-1шт.

1

2181-1186D17

ELBOW;HOSE PF1/2XPF3/8X90'

SERIAL: 1-3

2шт.

1

2181-1186D6

ELBOW;HOSE PF1/2XPF3/8X90'

SERIAL: 4

2шт.

2

2181-1913D22

REDUCER PFO3/8XPF1/2

desc: REDUCTEUR

2шт.

3

S8000141

O-RING P14

desc: JOINT TORIQUE

2шт.

4

2181-1702D36

ELBOW;HOSE PFO3/8XPF1/1X90'

desc: COUDE

1шт.

5

S8000141

O-RING P14

desc: JOINT TORIQUE

1шт.

6

2184-1026D292

HOSE PF1/2X1500L

desc: TUYAU FLEXIBLE

2шт.

7

2184-1060D122

HOSE PF1/2X1700L

desc: TUYAU FLEXIBLE

1шт.

8

2181-1702D15

ELBOW PFO1/2XPF1/2.90'

desc: COUDE

2шт.

9

S8000181

O-RING P18

desc: JOINT TORIQUE

1шт.

10

2181-1702D4

ELBOW;HOSE PFO1/4XPF1/4X90'

desc: COUDE

1шт.

11

S8000181

O-RING P18

desc: JOINT TORIQUE

1шт.

12

2181-2419D1

ELBOW;HOSE45'

desc: COUDE

1шт.

13

S8000181

O-RING P18

desc: JOINT TORIQUE

1шт.

14

2181-1702D10

ELBOW;HOSE PFO3/8XPF1/4X90'

desc: COUDE

2шт.

15

S8000111

O-RING P11

desc: JOINT TORIQUE

2шт.

16

2181-1702D51

ELBOW;HOSE PFO3/8XPF3/8X90'

desc: RACCORD

1шт.

17

S8000141

O-RING P14

desc: JOINT TORIQUE

2шт.

19

2181-1702D15

ELBOW PFO1/2XPF1/2.90'

desc: COUDE

1шт.

20

S8000110

O-RING P11

desc: JOINT TORIQUE

2шт.

21

2181-1702D13

ELBOW;HOSE PFO3/8XPF1/2X90'

SERIAL: 1-296

1шт.

22

S8000141

O-RING P14

desc: JOINT TORIQUE

1шт.

23

2184-1026D321

HOSE PF1/2X1420L

desc: TUYAU FLEXIBLE

1шт.

24

2184-1026D346

HOSE D/Z UPPF1/4X1200L

desc: TUYAU FLEXIBLE

1шт.

25

2184-1026D342

HOSE;SWING PF3/8X950L

SERIAL: 1-138

2шт.

25

2184-1026D29

HOSE PF3/8-800L

SERIAL: 139-183

2шт.

25

2184-1026D29

HOSE PF3/8-800L

SERIAL: 184

1шт.

26

2184-1026D3

HOSE D/Z DOWN PF1/4X1300L

desc: TUYAU FLEXIBLE

1шт.

27

2181-1126D7

ADAPTER PFO3/8XPF3/8

desc: RACCORD

2шт.

28

S8000141

O-RING P14

desc: JOINT TORIQUE

2шт.

29

2184-1026D3

HOSE PF1/4X1300

desc: TUYAU FLEXIBLE

1шт.

30

2184-1026D345

HOSE PF1/4X1400

desc: TUYAU FLEXIBLE

1шт.

31

2181-1702D10

ELBOW; HOSE PFO3/8XPF1/4X90'

desc: COUDE

1шт.

32

S8000141

O-RING P11

desc: JOINT TORIQUE

1шт.

33

2181-1702D52

ELBOW;HOSE PFO8/3XPF1/4X90'

desc: COUDE

1шт.

34

S8000111

O-RING P11

desc: JOINT TORIQUE

1шт.

35

2181-1126D14

ADAPTER PFO1/4XPF1/4

desc: RACCORD

1шт.

36

S8000111

O-RING P11

desc: JOINT TORIQUE

1шт.

37

2181-1126D14

ADAPTER PFO1/4XPF1/4

desc: RACCORD

1шт.

38

S8000111

O-RING P11

desc: JOINT TORIQUE

1шт.

39

2181-1702D35

ELBOW PFO3/8XPF1/2

desc: COUDE

1шт.

40

2181-1702D5

ELBOW PFO3/8XPF3/8.90'

desc: COUDE EN S

1шт.

41

2184-1026D342

HOSE PF3/8X950L

SERIAL: 184

1шт.

42

2181-1702D36

ELBOW UNF9/16

SERIAL: 297

1шт.
