Запчасти Doosan Daewoo ENGINE MOUNTING(2) - RADIATOR UPPER STRUCTURE

-

201-00206A

ENGINE MOUNT

SERIAL: 20592

-2шт.

6

S0512053

BOLT M10X1.5X25

desc: BOULON A 6PANS

4шт.

7

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

14

2197-1226B

BRACKET;RADIATOR(L.H)

desc: SUPPORT

1шт.

15

2114-1058D10

WASHER M10

desc: RONDELLE PLATE

4шт.

16

2197-1225B

BRACKET;RADIATOR(R.H)

desc: SUPPORT

1шт.

17

6202-6001

RADIATOR

desc: RADIATEUR

1шт.

18

S0508853

BOLT M8X1.25X20

desc: BOULON A 6PANS

8шт.

19

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

14шт.

20

S5010513

WASHER;PLAIN M8

desc: RONDELLE

14шт.

21

205-00032

SHROUD

desc: GARDE

1шт.

22

S0504453

BOLT M6X1.0X12

desc: BOULON A 6PANS

4шт.

23

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

6шт.

24

S5010313

WASHER;PLAIN M6

desc: RONDELLE

6шт.

25

40121-01051

COOLER;OIL

desc: REFROIDISSEUR D'HUILE

1шт.

26

2621-3279A

PLATE(L.H)

desc: PLAQUE

1шт.

27

2621-3278A

PLATE(R.H)

desc: PLAQUE

1шт.

28

621-03581

COVER;BAFFLE

desc: COUVERCLE

1шт.

29

S0508653

BOLT

desc: BOULON A 6PANS

3шт.

30

621-03582A

COVER;BAFFLE

desc: COUVERCLE

1шт.

31

185-00403

HOSE;UPPER

desc: TUYAU FLEXIBLE

1шт.

32

S8450044

BAND;WIRE

desc: COLLIER

2шт.

33

185-00409A

HOSE;LOWER

desc: TUYAU FLEXIBLE

1шт.

35

Z21256-44600

HANGER;SURGE TANK

desc: SUPPORT

1шт.

36

Z24450-44510

TANK;SURGE

desc: RESERVOIR

1шт.

37

S8450006

CLIP;HOSE

desc: COLLIER

1шт.

38

40124-00350

HOSE

desc: TUYAU FLEXIBLE

1шт.

39

30572-08012

CLIP

desc: ATTACHE

1шт.

47

145-00148

STAY

desc: ENTRETOISE

1шт.

48

S0504653

BOLT M6X1.0X16

desc: BOULON A 6PANS

2шт.

49

161-00658

SPONGE ASS'Y

desc: EPONGE

1шт.

50

162-00029A

STRIP;WEATHER 1000L

desc: BANDE

1шт.

51

2160-1023

TRIM;RUBBER 350L

desc: EPONGE

1шт.

52

S0508953

BOLT

desc: BOULON A 6PANS

2шт.

54

S8450035

CLAMP

desc: ATTACHE

2шт.

55

Z24450-44550

CLAMP

desc: ATTACHE

1шт.

57

K1010549

SENSOR;WATER TEMP

desc: CAPTEUR

1шт.
