Запчасти Doosan Daewoo CANOPY UPPER STRUCTURE

-

2622-7022

ROOF

SC: D

-2шт.

1

622-00330

ROOF

desc: PORTD

1шт.

2

S0515053

BOLT M12X1.75X25

desc: BOULON A 6PANS

8шт.

3

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

10шт.

4

S5010713

WASHER;PLAIN M12

desc: RONDELLE

10шт.

5

2197-1220B

BRACKET ROOF

desc: SUPPORT

1шт.

6

2197-1262C

BRACKET

desc: SUPPORT

1шт.

7

S0515053

BOLT

desc: BOULON A 6PANS

2шт.

8

2161-2062

PLATE;RUBBER

desc: PLAQUE CAOUTCHOUC

1шт.

9

2197-1219A

POST;ROOF(R.H)

desc: SUPPORT

1шт.

10

S0512053

BOLT M10X1.5X25

desc: BOULON A 6PANS

8шт.

11

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

8шт.

12

S5010603

WASHER;PLAIN M10

desc: RONDELLE PLATE

8шт.

13

2197-1218A

POST;ROOF(L.H)

desc: SUPPORT

1шт.

14

2114-1769

WASHER

desc: RONDELLE PLATE

4шт.

16

2142-1110G

RAIL;HAND

desc: RAIL

1шт.

17

S0508853

BOLT M8X1.25X20

desc: BOULON A 6PANS

4шт.

18

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

19

2114-1058D29

WASHER M8

desc: RONDELLE

4шт.

20

2142-1111H

RAIL;HAND

desc: RAIL

1шт.

21

S0515053

BOLT M12X1.75X25

desc: BOULON A 6PANS

2шт.

22

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

2шт.

23

S5010713

WASHER;PLAIN M12

desc: RONDELLE

2шт.

24

2737-1002C

COVER;TANK

desc: COUVERCLE

1шт.

25

S0508653

BOLT M8X1.25X16

desc: BOULON A 6PANS

6шт.

26

2114-1058D29

WASHER M8

desc: RONDELLE

6шт.

28

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

6шт.
