Запчасти Doosan Daewoo ENGINE MOUNTING(3)-INTAKE & EXHAUST UPPER STRUCTURE

-

201-00086

ENGINE ASS'Y

SC: D

-2шт.

1

185-00281

HOSE;AIR CLEANER

desc: TUYAU FLEXIBLE

1шт.

2

S8450044

BAND;WIRE

desc: COLLIER

2шт.

9

2182-1556

PIPE;TAIL

desc: TUYAU

1шт.

10

894473-5630

CLAMP;EXH PIPE

desc: ATTACHE DE TUYAU

1шт.

11

S0556653

BOLT M8X1.25X65

desc: BOULON A 6 PANS

1шт.

12

S5010513

WASHER M8

desc: RONDELLE PLATE

2шт.

13

S4012533

NUT M8

desc: ECROU

1шт.

14

2197-1287

BRACKET;TAIL PIPE

desc: SUPPORT

1шт.

15

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

2шт.

16

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

17

2114-1058D10

WASHER

desc: RONDELLE PLATE

2шт.

18

2120-1413D9

BOLT;U

desc: BOULON EN U

1шт.

19

2114-1058D10

WASHER

desc: RONDELLE PLATE

2шт.

20

S4012633

NUT M10X1.5

desc: ECROU

2шт.

21

S5102503

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.
