Запчасти Doosan Daewoo CONTROL STAND(2)-R.H-CABIN TYPE OPTIONAL PARTS

-

195-00384B

CONTROL STAND ASS'Y

SERIAL: 1001-1054

-2шт.

-

195-00384C

CONTROL STAND ASS'Y

SERIAL: 1055

-2шт.

2

621-01083A

COVER;SWITCH(R.H)

desc: COUVERCLE

1шт.

7

2120-2166D38

BOLT M8X1.25X35

desc: BOULON A 6 PANS

2шт.

10

2120-2166D33

SCREW M4X0.7X10

desc: VIS

2шт.

12

195-00388A

BRACKET(R.H)

desc: SUPPORT

1шт.

22

S5110303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

4шт.

24

2120-2166D25

BOLT M8X1.25X16

desc: BOULON A 6 PANS

2шт.

25

2114-1898D2

WASHER M8

desc: RONDELLE

10шт.

26

2120-2166D5

BOLT M8X1.25X20

desc: BOULON A 6 PANS

6шт.

29

2125-1078B

CASE;UPPER

desc: CARTER

1шт.

30

125-00020

CASE;LOWER

desc: CARTER

1шт.

31

2195-3763B

BRACKET

desc: SUPPORT

1шт.

37

2114-1898D13

WASHER M4

desc: RONDELLE PLATE

2шт.

40

2120-2166D22

SCREW M3X0.5X12

desc: VIS

2шт.

41

2114-1898D4

WASHER M5

desc: RONDELE DE ELASTIQUE

6шт.

42

2120-2166D23

SCREW M5X0.8X20

desc: VIS

6шт.

45

2120-2166D23

SCREW M5X0.8X20

desc: VIS

2шт.

46

2114-1058D64

WASHER

desc: RONDELLE

2шт.

49

195-01102A

BRACKET

desc: SUPPORT

1шт.

50

195-01103A

BRACKET

desc: SUPPORT

1шт.

51

195-00389A

BRACKET

desc: SUPPORT

1шт.

52

2120-2166D18

SCREW M5X0.8X10

desc: VIS

4шт.

57

S0505053

BOLT M6X1.0X25

desc: BOULON A 6 PANS

4шт.
