Запчасти Doosan Daewoo WORK EQUIPMENT PIPING FRONT ATTACHMENTS

1

2181-1126D7

ADAPTER PF3/8XPF3/8

desc: RACCORD

2шт.

2

S8000141

O-RING

desc: JOINT TORIQUE

2шт.

3

2193-1361A

PIPE;ARM

desc: TUYAU DE BALANCIER

2шт.

4

2193-1362C

PIPE;BUCKET(R.H)

desc: CONDUITE

1шт.

5

2193-1362C

PIPE;BUCKET(R.H)

desc: CONDUITE

1шт.

6

2124-1025D9

CLAMP;PIPE

desc: ATTACHE DE TUYAU

4шт.

7

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

4шт.

8

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

9

2124-1559

CLAMP;PIPE

desc: ATTACHE DE TUYAU

4шт.

10

S0555953

BOLT

desc: BOULON A 6 PANS

4шт.

11

S5102503

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

12

S4012533

NUT

desc: ECROU

4шт.

13

2184-1026D192

HOSE PF3/8-820L

desc: TUYAU FLEXIBLE

2шт.

14

2184-1054D34

HOSE PF3/8-650L

desc: TUYAU FLEXIBLE

2шт.

15

2181-1126D7

ADAPTER PF3/8XPF3/8

desc: RACCORD

2шт.

16

S8000141

O-RING

desc: JOINT TORIQUE

2шт.

17

2185-1623D3

HOSE 750L

desc: TUYAU FLEXIBLE

2шт.
