Запчасти Doosan Daewoo ENGINE MOUNTING(3) - INTAKE & EXHAUST UPPER STRUCTURE

-

201-00086

ENGINE MOUNT

SERIAL: 20001-20575

-2шт.

6

S0512053

BOLT M10X1.5X25

desc: BOULON A 6PANS

2шт.

7

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

15

2114-1058D10

WASHER

desc: RONDELLE PLATE

4шт.

19

S5102503

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

20

S5010513

WASHER M8

desc: RONDELLE

2шт.

32

S8450044

BAND;WIRE

SERIAL: 20001-20410

2шт.

32

S8450044

BAND;WIRE

SERIAL: 20411

3шт.

34

185-00281

HOSE;AIR CLEANER

desc: TUYAU FLEXIBLE

1шт.

40

2197-1287

BRACKET;TAIL PIPE

desc: SUPPORT

1шт.

41

2182-1556

PIPE;TAIL

desc: TUYAU

1шт.

42

894473-5630

CLAMP;EXH PIPE

desc: ATTACHE DE TUYAU

1шт.

43

S0556653

BOLT M8X1.25X65

desc: BOULON A 6PANS

1шт.

44

S4012533

NUT M8

desc: ECROU

1шт.

45

2120-1413D9

BOLT;U

desc: BOULON DE U

1шт.

46

S4012633

NUT M10X1.5

desc: ECROU

2шт.

54

K1008253

HOSE;AIR

SERIAL: 20411

1шт.
