/ / / / / ENGINE MOUNTING(1) - ENGINE
Запчасти Doosan Daewoo ENGINE MOUNTING(1) - ENGINE UPPER STRUCTURE
1
3
4
12
7
13
6
7
8
10
9
53
3
3
4
3
6
4
7
8
3
5
4
9
11
6
7
5
8
2
7
53
12
3
7
8
6
53
10
3
2
53
3
-
201-00206A
ENGINE MOUNT
SERIAL: 20576
-2шт.
1
201-00232A
ENGINE ASS'Y
desc: MOTEUR
1шт.
2
41801-00130
RUBBER;ABSORBER
desc: CAOUTCHOUC
2шт.
3
S4012733
NUT M12X1.75
desc: ECROU
8шт.
4
2114-1058D46
WASHER
desc: RONDELLE
4шт.
5
2161-2051A
STOPPER
desc: TAQUET D'ARRET
2шт.
6
S0512053
BOLT M10X1.5X25
desc: BOULON A 6PANS
8шт.
7
S5102603
WASHER;SPRING M10
desc: RONDELLE ELASTIQUE
18шт.
8
S5010613
WASHER;PLAIN M10
desc: RONDELLE PLATE
8шт.
9
2161-2052A
STOPPER(R.H)
desc: TAQUET D'ARRET
2шт.
10
2161-9051
RUBBER;MOUNTING
desc: CAOUTCHOUC
2шт.
11
195-03321
BRACKET;ENGINE(B)
desc: SUPPORT
1шт.
12
S0512253
BOLT M10X1.5X30
desc: BOULON A 6PANS
8шт.
13
195-03320
BRACKET;ENGINE(A)
desc: SUPPORT
1шт.
53
S5102703
WASHER;SPRING M12
desc: RONDELLE ELASTIQUE
4шт.
