Запчасти Doosan Daewoo CONTROL VALVE(1) TRACK PARTS

1

2420-9393

CONTROL VALVE ASS'Y

SERIAL: 1-433

1шт.

2

06241-06000

INLET SECTION ASS'Y

desc: TIROIRS DE COMMANDE

1шт.

3

06470-05300

BLOCK ASS'Y-TRAVEL(L)

desc: BLOC

1шт.

4

07307-05200

BLOCK ASS'Y

desc: BLOC

1шт.

5

07307-05600

BLOCK ASS'Y-ARM

desc: BLOC

1шт.

6

07307-05100

BLOCK ASS'Y-PTO

desc: BLOC

1шт.

7

06470-06100

BLOCK ASS'Y-TRAVEL(R)

desc: BLOC

1шт.

8

07370-05400

BLOCK ASS'Y-BUCKET

desc: BLOC

1шт.

9

07370-05500

BLOCK ASS'Y-BOOM

desc: BLOC

1шт.

10

06470-06300

BLOCK ASS'Y

desc: BLOC

1шт.

11

06470-06100

BLOCK ASS'Y-ARM SWING

desc: BLOC

1шт.

12

06470-05700

BLOCK ASS'Y-DOZER

desc: BLOC

1шт.

13

07370-05800

BLOCK ASS'Y-SWING

desc: BLOC

1шт.

14

06470-06200

INLET SECTION ASS'Y

desc: TIROIRS DE COMMANDE

1шт.

15

86781-00017

O-RING

desc: JOINT TORIQUE

24шт.

16

86781-00030

O-RING AS568-21

desc: JOINT TORIQUE

1шт.

17

86781-00031

O-RING AS568-31

desc: JOINT TORIQUE

1шт.

18

07370-05000

MAIN RELIEF V/V ASS'Y

desc: ENSEMBLE CLAPET DECHARGE

2шт.

19

86711-02018

O-RING 1B P18

desc: JOINT TORIQUE

2шт.

20

86711-02012

O-RING 1B P12

desc: JOINT TORIQUE

2шт.

21

07370-05200

COMBINATION VALVE ASS'Y

desc: VANNE

4шт.

22

86711-02016

O-RING 1B P16

desc: JOINT TORIQUE

1шт.

23

86711-01010

O-RING 1B P10

desc: JOINT TORIQUE

1шт.

24

07370-05300

PORT RELIEF VALVE ASS'Y

desc: PORT VANNE

1шт.

25

86711-02016

O-RING 1B P16

desc: JOINT TORIQUE

1шт.

26

86711-01010

O-RING 1B P10

desc: JOINT TORIQUE

1шт.

27

06212-06400

SUCTION CHECK VALVE ASS'Y

desc: VANNE

1шт.

28

86711-02016

O-RING 1B P16

desc: JOINT TORIQUE

1шт.

29

86711-01010

O-RING 1B P10

desc: JOINT TORIQUE

1шт.

30

87143-00002

PLUG

desc: BOUCHON

3шт.

31

87143-00005

PLUG

desc: BOUCHON

1шт.

32

05235-10600

ROD;TIE

desc: TIGE

4шт.

33

83203-10080

NUT

desc: ECROU

8шт.

34

07370-05100

MAIN RELIEF V/V ASS'Y(P3)

desc: ENSEMBLE CLAPET DECHARGE

1шт.
