Запчасти Doosan Daewoo INJECTION PUMP.CAM SHAFT.IDLE GEAR ENGINE PARTS

1

897034-5915

PUMP ASS'Y;INJ PFR FIG 119

desc: ENSEMBLE DE POMPE

3шт.

3

897034-6152

SHIM;INJ PUMP T=0.2

desc: CALE

1шт.

3

897034-6162

SHIM;INJ PUMP T=0.3

SC: R

1шт.

3

897034-6172

SHIM;INJ PUMP T=0.4

SC: R

1шт.

3

897126-3590

SHIM;INJ PUMP T=0.5

SC: R

1шт.

3

897034-6192

SHIM;INJ PUMP T=0.6

SC: R

1шт.

3

897034-6202

SHIM;INJ PUMP T=0.7

SC: R

1шт.

3

897034-6212

SHIM;INJ PUMP T=0.8

SC: R

1шт.

3

897034-6222

SHIM;INJ PUMP T=1.0

SC: R

1шт.

3

897034-6232

SHIM;INJ PUMP T=1.2

SC: R

6шт.

5

091150-2080

NUT;INJ PUMP FIX

desc: ECROU

6шт.

6

028080-8200

BOLT;INJ PUMP FIX

desc: BOULON A 6 PANS

1шт.

10

897062-1401

SHAFT;CAM INJ.PUMP

desc: ARBRE

1шт.

12

897062-0480

RING;WEARCAMSHAFT FRT

desc: BAGUE

1шт.

13

909878-6260

PIN;CAMSHAFT

desc: BROCHE

1шт.

14

900090-6100

BEARING;BALL FRONT

desc: PALIER

1шт.

15

900090-6570

BEARING;BALL REAR

desc: PALIER

1шт.

18

897102-2880

GEAR;INJ PUMP VALVE Z=74

desc: PIGNON

1шт.

19

509400-0530

NUT;CAM GEAR FIX

desc: ECROU

1шт.

20

909180-1620

RING;SNAP CAMSHAFT FIX

desc: BAGUE

1шт.

25

897129-7800

SHAFT ASS'Y;IDLE GEAR

desc: ARBRE

1шт.

26

897129-7820

GEAR;W/BUSH IDLE (A) Z=44

desc: PIGNON

1шт.

27

512535-0051

COLLAR;THRUST IDLE GEAR

desc: COLLIER

1шт.

28

028090-8450

BOLT;SHAFT FIX

desc: BOULON A 6 PANS

2шт.

32

894241-1792

PUMP ASS'Y;FUEL ELECT 12V

desc: ENSEMBLE DE POMPE

1шт.

33

894233-6550

GROMMET;FUEL PUMP

desc: MANCHON CAOUTCHOUC

2шт.

34

894238-9070

COLLAR;FUEL PUMP

desc: COLLIER

2шт.

35

901910-6280

SCREW;FUEL PUMP

desc: VIS

2шт.

36

894233-6570

WASHER FUEL PUMP

desc: RONDELLE PLATE

2шт.
