Запчасти Doosan Daewoo SEAT PLATE BODY PARTS

-

195-00384A

CONTROL STAND ASS'Y

SC: D

-2шт.

1

621-00496B

PLATE;FLOOR

desc: PLAQUE

1шт.

3

195-00390B

BRACKET;FUSE BOX

desc: SUPPORT

1шт.

4

621-01077

COVER

desc: COUVERCLE

1шт.

6

195-00385A

BRACKET;STAND(L.H)

desc: SUPPORT

1шт.

8

195-00391

BRACKET;ACCEL

desc: SUPPORT

1шт.

24

2120-2166D25

BOLT M8X1.25X16

desc: BOULON A 6 PANS

6шт.

25

2114-1898D2

WASHER M8

desc: RONDELLE

19шт.

26

2120-2166D5

BOLT M8X1.25X20

desc: BOULON A 6 PANS

9шт.

27

621-00493B

COVER(L.H)

desc: COUVERCLE

1шт.

28

621-00494

COVER(R.H)

desc: COUVERCLE

1шт.

32

2120-2166D19

BOLT M6X1.0X12

desc: BOULON A 6 PANS

8шт.

33

2114-1898D5

WASHER M6

desc: RONDELLE

8шт.

43

2114-2031D4

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

9шт.

44

2160-1004D2

BUSHING;RUBBER

desc: MANCHON CAOUTCHOUC

2шт.

47

2120-2166D16

BOLT M8X1.25X25

desc: BOULON A 6 PANS

4шт.

48

2160-1330

BUSHING;RUBBER

desc: DOUILLE

1шт.

53

2161-2462

BUSHING;RUBBER

desc: DOUILLE

4шт.
