Запчасти Doosan Daewoo POWER UNIT(3) BODY PARTS

-

2201-7012

ENGINE MOUNT

desc: BATI MOTEUR

1шт.

1

11430-01650

HOSE;AIR CLEANER

desc: TUYAU FLEXIBLE

1шт.

2

S8450044

BAND;WIRE

desc: BRIDE DE FIXATION

2шт.

3

2197-1286

BRACKET;PIPE

desc: SUPPORT

1шт.

4

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

2шт.

5

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

6

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

2шт.

7

2184-1258

HOSE 386L

desc: TUYAU FLEXIBLE

1шт.

8

S8450053

BAND;WIRE

desc: BRIDE DE FIXATION

1шт.

9

2182-1617

PIPE;TAIL

SERIAL: 1-168

1шт.

9

2182-1617A

PIPE;TAIL

SERIAL: 169-230

1шт.

9

2182-1617B

PIPE;TAIL

SERIAL: 231

1шт.

10

894473-5630

CLAMP;EXH PIPE

desc: ATTACHE DE TUYAU

1шт.

11

S0556653

BOLT M8X1.25X60

desc: BOULON A 6 PANS

1шт.

12

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

2шт.

13

S4012533

NUT M8X1.25

desc: ECROU HEXAGONAL

1шт.

14

2197-1287

BRACKET;TAIL PIPE

desc: SUPPORT

1шт.

15

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

2шт.

16

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

17

2114-1058D10

WASHER

desc: RONDELLE PLATE

2шт.

18

2120-1413D9

BOLT;U

desc: BOULON EN U

1шт.

19

2114-1058D10

WASHER

desc: RONDELLE PLATE

2шт.

20

S4012633

NUT M10X1.5

desc: ECROU HEXAGONAL

2шт.
