Запчасти Doosan Daewoo TRACK FRAME-1300MM TRACK PARTS

-

604-00100

TRACK ASS'Y

SC: D

-2шт.

1

604-00092A

FRAME;TRACK

desc: TRAIN DE ROULEMENT

1шт.

3

2621-3902A

COVER

desc: COUVERCLE

2шт.

4

2621-3903A

COVER

SERIAL: 1001-1176

1шт.

4

2621-3903B

COVER

SERIAL: 1177

1шт.

5

270-00008

ROLLER;TRACK

desc: GALET INFERIEUR

6шт.

6

2440-9266A

CYLINDER;GREASE

desc: VERIN

2шт.

7

270-00010

IDLER;FRONT

desc: BARBOTIN

2шт.

8

401-00082

MOTOR;TRAVEL

SERIAL: 1001-1204

2шт.

8

401-00372

MOTOR;TRAVEL

SERIAL: 1205

2шт.

9

2108-1044

SPROCKET

desc: COURONNE DENTEE

2шт.

10

109-00130

BEARING;SWING

desc: PALIER D'ORIENTATION

1шт.

10A

180-00297D1

SEAL

desc: . JOINT

1шт.

12

273-00038

RUBBER;CRAWLER

desc: CAOUTCHOUC

2шт.

13

S0508853

BOLT M8X1.25X20

desc: BOULON A 6 PANS

6шт.

14

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

10шт.

15

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

10шт.

16

S0508453

BOLT M8X1.25X12

desc: BOULON A 6 PANS

4шт.

17

S2212061

BOLT;SOCKET M10X1.5X25

desc: BOULON A 6 PANS CREUX

34шт.

18

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

34шт.

20

S0515561

BOLT M12X1.75X45

desc: BOULON A 6 PANS

18шт.

22

S0760761

BOLT M12X1.25X50

desc: BOULON A 6 PANS

18шт.
