Запчасти Doosan Daewoo OIL PAN & GEAR CASE ENGINE PARTS

1

MM432235

CAP;SEALING

desc: BOUCHON

1шт.

2

30L11-00040

GEAR CASE ASS'Y

desc: PIGNON

1шт.

2-1

MD000312

GASKET

desc: . JOINT

1шт.

2-2

MD001402

PLUNGER

desc: . PLONGEUR

1шт.

2-3

MD001404

PLUG

desc: . BOUCHON

1шт.

2-4

MF241231

BOLT;WITH WASHER

desc: . BOULON A 6 PANS

3шт.

2-5

MM433353

SPRING;RELIEF

desc: . RESSORT

1шт.

2-6

MM433793

GEAR;OIL PUMP INNER

desc: . PIGNON

1шт.

2-7

MM433794

GEAR;OIL PUMP OUTER

desc: . PIGNON

1шт.

2-8

MM434466

HOUSING;OIL PUMP

desc: . CARTER

1шт.

2-9

MS661121

PLUG;TAPER

desc: . BOUCHON

1шт.

2-10

MS661140

PLUG;TAPER

desc: . BOUCHON

1шт.

2-11

30L11-00020

GEAR CASE SUB ASS'Y

desc: . PIGNON

1шт.

3

30L11-05100

GASKET;GEAR CASE

desc: JOINT

1шт.

4

MD008883

SEAL;OIL

desc: JOINT D'HUILE

1шт.

5

MF101235

BOLT

desc: BOULON A 6 PANS

3шт.

6

MF101240

BOLT

desc: BOULON A 6 PANS

4шт.

7

MF101242

BOLT

desc: BOULON A 6 PANS

1шт.

8

MF240051

BOLT;WITH WASHER

desc: BOULON A 6 PANS

3шт.

9

MF241224

BOLT;WITH WASHER

desc: BOULON A 6 PANS

4шт.

10

MF520007

O-RING

desc: JOINT TORIQUE

2шт.

11

MM437065

OIL PAN ASS'Y

desc: ENSEMBLE CARTER D'HUILE

1шт.

11-1

MD000312

GASKET

desc: . JOINT

1шт.

11-2

MD000318

PLUG;OIL DRAIN

desc: . BOUCHON

1шт.

12

30L13-05200

GASKET;OIL PAN

desc: JOINT

1шт.

13

MF241223

BOLT

desc: BOULON A 6 PANS

18шт.

14

MM300540

OIL FILTER CAP ASS'Y

desc: VIBREUR

1шт.

14-1

MF520402

O-RING

desc: . JOINT TORIQUE

1шт.
